No

Kod

Parça Adı

1

121966

Compressor (SANKYO 507)

2

122448

Lower bracket

3

146914

Upper mounting

4

122418

SCREW

13

12574521

Nut

6

12601474

WASHER

7

121928

Silentblock

8

102695

WASHER

9

11343821

SCREW

10

102742

Nut

11

15970921

SCREW

12

122947

Bush

14

14496624 | 675000766

WASHER

15

124333

Fitting for intake

16

124334

Fitting for outlet

17

122422

Clutch - clock wise rotation

18

122973

A.C. compressor control belt

19

61470700

Pipe condenser to receiver drier

20

61470800

Pipe receiver drier to evaporator

21

61470900

Pipe evaporator to compressor

22

61471000

Pipe compressor to condenser

23

61400000

A.C. assembly

24

60870300

Conveyor

25

11087876

FLEXIBLE RING

26

117546

Fan motor

27

61701500

Lower gasket

28

123298

SCREW

29

61742600

Expansion valve

30

61989500

FILTER

31

60649100

Condenser

32

61358300

Front housing

33

61047900

Thermo - switch

34

60815000

Spring

35

122953

4 blade fan

36

61701400

Upper gasket

37

61701300

Lateral gasket

38

10902511

SCREW

39

103549

Cable Grommet

40

103550

Spacer bush -Only for

41

12643724

WASHER

42

12601374

Washer

43

14039614

NUT

44

122449

Spacer
