No

Kod

Parça Adı

1

125456

Clutch housing, complete

2

16044024

SCREW

18

12601374

Washer

4

125537

Dowel

5

121797

Bush for bearing

6

121806

Inspection cover

7

11000824

Stud -Q.ty 4 for USA-

8

14059114

NUT

9

12601174

Washer

10

114603

Timing reference bracket

11

10977824

SCREW

38

127493

WASHER

13

148604

THREADED UNION

14

10261460

Gasket

15

123885

Exhaust valve

16

13543424

STUD BOLT

20

14040711

NUT

18

120016

Clutch Ø 8''½ complete

19

109460

FRIZIONE DOPPIO DISCO D. 8 1

21

119496

Rigid driven plate

22

119495

Spring hub driven plate

23

108515

Spacer

24

109464

Intermediate plate

25

109465

Stud

26

109466

Washer

27

109880

Dowel

28

110019

Stud

49

127496

Washer

30

123689

Clutch shaft

31

126223

Bearing

32

10440990

BRACKET WITH SHEATH

33

125458

Thrust bearing

34

123359

Bush for bearing

35

123360

Sleeve for bush

36

123696

Plate

37

10977521

SCREW

39

139440

Sealing ring

40

139439

Sealing ring -Valid after

41

65928500

THREADED PLUG

42

233118

O-RING

43

121814

Sealing ring

44

138680

Sealing ring

45

121717

Pre load spring

46

123110

Safety ring

47

152954

BLEED SCREW

48

13516624

STUD BOLT

50

16108811

Nut

51

123309

Flexible hose

52

110810

Pipe securing plate

53

123308

Pipe
