No

Kod

Parça Adı

1

128794

Crankshaft

2

14326150

CAP

3

100119

1st undersize 0,254 mm. on Ø

3

100120

2nd undersize 0,508 mm on Ø

3

100118

UPPER HALF BEARING

4

100123

1st undersize 0,254 mm. on Ø

4

100124

2nd undersize 0,508 mm on Ø

4

100122

LOWER HALF BEARING

5

153214

HALF BEARING SET - 1st UNDERSIZE mm. 0,254

5

104025

2nd undersize 0,508 mm on Ø

5

104023

UPPER AND LOWER HALF BEARING

6

113984

SHIM 1st OVERSIZE mm 0.127

6

100147

SHIM 2nd OVERSIZE mm 0.250

6

4150813

Shim for rear support

7

10206020

Tongue

9

122064

Connecting rod, complete

10

100156

CONNECTING ROD TIGHTENING SCREW

11

104011

CONNECTING ROD TIGHTENING NUT

12

106184

1st undersize 0,254 mm. on Ø

12

106185

2nd undersize 0,508 mm on Ø

12

106183

CONNECTING ROD HALF BEARING

13

121974

Bush for gudgeon pin

14

121975

Gudgeon pin

15

100174

Ring for gudgeon pin

16

122453

Piston with piston ring

17

121954

Driving sprocket for timing sys.

17

125667

Set of piston rings

18

122457

AC conical seal ring (1st- 2nd groove)

19

119535

ROF scraper ring with spring (3td groove)

20

122610

Torsion damper with pulley

21

138793

SCREW

22

138792

WASHER

23

103877

Shaft Bearing

24

123381

Engine flywheel

25

201755

Screw

26

215963

WASHER

27

123317

Dowel

28

200323

Gasket

29

109316

Driving gear for scavenge pump
