Ferrari Yedek Parça - 288 GTO - Doors
Parça Kodları
No
Kod
Parça Adı
1
61404800
Left door
1
61404700
Right door
2
50031608
Mobile hinge, lower
3
60265501
Mobile hinge, upper L.H.
3
60265402
Mobile hinge, upper R.H.
4
63026200
Pin for door hinge
5
11065774
Seeger Ring
6
61384700
L.H. safety rod
6
60059409
R.H. safety rod
7
30016109
Spring
8
20170403
Knob for safety rod
9
61617500
BUSHING
10
61407200
Tie rod
11
65859300
Rod pin
12
61674100
Left glass frame
12
61674000
Right glass frame
13
60263902
Left mobile glass
13
60263803
Right mobile glass
14
60264504
Left fixed glass
14
60264405
Right fixed glass
15
61420700
Light rear mirror
15
61420600
Right rear mirror
16
61612600
Left window regulator manual
16
61612700
Right window regulator manual
17
61612900
Left bracket
17
61612800
Right bracket
18
61613100
Left central bracket
18
61613000
Right central bracket
19
61613200
Bush
20
61613300
Handle for window regulator
21
61613400
Ring nut under handle
22
61613500
Spring for handle
23
61330100
Left electric window regulator
23
61723700
Right electric window regulator
24
61612000
Left bracket
24
61611900
Right bracket
25
61439900
Door bandit, inside
26
61439800
Moulding for handle
27
61775700
Left outer covering
27
61775600
Right outer covering
28
60265600
Fixed hinge
29
60269404
Fixing plate for fixed hinge
30
60734000
Zincofil
31
50206408
Screw
32
16286127
SCREW
59
12644424
Washer
34
12035671
Washer
35
10902221
SCREW
36
231625
Screw
37
20030003
Screw
38
13273906
Screw
39
60702900
Washer
40
11197774
Washer
41
60892600
Rubber
42
20286704
Screw
65
14039614
NUT
44
40195703
Plug
45
10902224
SCREW
46
14496501
WASHER
47
60056306
Pulley
48
61409000
Left outsider handle
48
61408900
Right outsider handle
49
12601374
Washer
50
60657800
Screw
51
13832101
NUT
52
12643724
WASHER
53
12648925
WASHER
54
50086909
Bushing
55
60441409
Spacer
56
319201
FUEL FILLER PIPE ASSEMBLY
57
12638124
Washer
58
60078805
Pin
60
14141410
Screw
61
60441607
Bush
62
60116803
Cable
63
60302205
Rear channel
66
61671500
Covering for ieft panel
66
61671400
Covering for right panel
66
61407700
Left panel with covering
66
61407600
Right panel with covering
67
61614100
Grill for loud-speaker
68
60273901
Pin for outsider handle
69
60088705
Special screw
70
61455000
Left front half rod
70
61454900
Right front half rod
71
60632800
Rear half rod
72
60088606
Sleeve
73
40063208
CABLE RETAIN CLIP
74
61611500
Clip
75
61672400
Left lock
75
61672390
Right lock
76
20298303
Screw
77
20037008
Spring
78
60606600
Left block
78
60606500
Right block
78
60046000
Spring
80
40133902
Terminal
81
60709000
Tie rod
82
61723000
Lock
83
20063202
Ring
84
20035804
Spacer
85
61456100
Left front moulding
85
61456000
Right front moulding
86
60304904
Left moulding
86
60304805
Right moulding
87
60269305
Left rear moulding
87
60269206
Right rear moulding
88
15908502
Screw
89
61741400
Left moulding
89
61741300
Right moulding
90
16324135
Weatherstrip, fixed glass GTB/S
91
60302106
Front channel
92
60278405
Rear gasket
93
40056103
Upper external rubber
95
60827600
Gasket L.H. outsider, R.H. inside
96
20181103
Gasket
97
61455400
Gasket
98
60159605
Gasket
99
40127409
Plug
100
61668000
Reflector
101
61737400
ROOF LAMP FOR PASSENGERS COMPARTMENT LIGHTING
102
61631300
Left gasket
102
61631200
Right gasket
103
61667200
Loud-speaker
104
61455600
Left inside handle with covering
104
61455500
Right inside handle with covering
105
61762000
Left moulding fixing gasket
105
61761900
Right moulding fixing gasket
106
61763300
Under door gasket
