No

Kod

Parça Adı

-

63641700

ANGLE PIECE FOR RH REAR GLASS SCRAPER

34

65055800

L.H. SMALL PLATE

-

63645300

COMPLETE L.H. GLASS LIFT

-

62107200

COMPLETE R.H. GLASS LIFT

-

63645200

COMPLETE R.H. GLASS LIFT

-

62302100

R.H. GLASS LIFTING MOTOR

-

63641600

L.H. GLASS INNER GASKET

-

62153300

R.H. GLASS INNER GASKET

-

63641500

R.H. GLASS INNER GASKET

-

62212900

RH DOOR REAR ANGULAR GASKET

-

62212000

R.H. DOOR REAR ANGLE PIECE

-

62213100

RH DOOR BELT HEIGHT GASKET

-

62104300

R.H. DOOR GLASS

-

64250900

R.H. DOOR GLASS

-

64251000

L.H. DOOR GLASS

-

62122700

R.H. FRONT GLASS GUIDE

1

62122800

L.H. FRONT GLASS GUIDE

2

12646604

WASHER

3

13276211

SCREW

4

62008600

RUBBER PAD

5

63301800

SCREW

6

60123502

PASSENGER SIDE CLIP

38

13832101

NUT

8

62008400

GLASS STOP RUBBER PAD

9

62106100

GLASS FRONT BRACKET

10

62104400

L.H. DOOR GLASS

11

63238800

LOWER RUBBER PAD

12

62213200

LH DOOR BELT HEIGHT GASKET

13

62106600

OUTER BUSHING

14

10902424

Screw

15

11197774

Washer

16

62106300

GLASS REAR BRACKET

17

62213000

LH DOOR REAR ANGULAR GASKET

18

62212100

L.H. DOOR REAR ANGLE PIECE

19

62940900

Screw

20

63314400

WASHER

21

62153400

L.H. GLASS INNER GASKET

22

62106700

INNER BUSHING

23

62211900

PAD

24

62302200

L.H. GLASS LIFTING MOTOR

25

63301700

SPACER

26

63301900

ELECTRIC WIRING FOR MOTOR

27

62107300

COMPLETE L.H. GLASS LIFT

28

13836371

SCREW

29

63000900

WATER PROTECTION CLOTH

33

14039614

NUT

31

63013600

ANGLE PIECE FOR GLASS SCRAPER

32

12648925

WASHER

35

13271617

SCREW

36

15687970

VITE -Non pi fornito- -Sostituito dal 15687909-

37

12601374

Washer

39

63994800

DOOR HANDLE WATER PROTECTION CLOTH

40

62106500

LOWER GASKET

41

63644300

ANGLE PIECE FOR LH REAR GLASS SCRAPER

42

63012900

BI ADHESIVE FOR GASKET FASTENING

43

154770

ELECTRIC BOARD FIXING BRACKET

44

10519424

WASHER

45

10977524

SCREW

46

154769

GLASS LIFTING MOTOR ELECTRIC BOARD

47

14496324

WASHER

48

319201

FUEL FILLER PIPE ASSEMBLY

49

15908506

SCREW

50

154762

MICRO SWITCH

51

155907

SPRING
