No

Kod

Parça Adı

1

136278

REAR SILENCER

2

136894

TERMINAL COVER

3

136277

FRONT MUFFLER

34

154984

Gasket

38

137431

SCREW

39

128010

Washer

40

114749

Shim

41

111743

Spring

9

62663300

EXHAUST PROTECTION PANEL

58

114748

Nut

11

14306924

SCREW

14

136877

BRACKET

15

139180

PAD

16

10977624

SCREW

17

15896470

NUT

18

127493

WASHER

19

137534

SCREW

22

10007871

FORK FOR BRAKE LEVER

23

10050814

PIN

24

84653800

WASHER

25

10734301

SPLIT PIN

26

145741

SMALL PLATE

27

16043221

SCREW

28

127496

Washer

54

14039614

NUT

30

12644424

Washer

31

136275

R.H. EXHAUST MANIFOLD

32

136276

L.H. EXHAUST MANIFOLD

33

138076

GASKET

35

110860

THREADED PLUG

36

10298460

Gasket

37

160506

RH/LH Catalyst

37

151609

EXHAUST PRE-MUFFLER

37

143871

EXHAUST PRE-MUFFLER

42

141874

STUB PIPE COMPLETE OF FLANGE

43

121515

OXYGEN SENSOR

44

151667

OXYGEN SENSOR

44

146650

OXYGEN SENSOR

44

142514

OXYGEN SENSOR

45

141037

CONTROL STATION

46

142581

Catalyst electric board

47

145487

BRACKET

48

145473

CLIP

49

12574017

NUT

50

14496204

WASHER

51

62844200

BRACKET FOR CONTROL UNIT FIXING

52

10444621

SCREW

53

143851

SUPPORT

55

14499370

Washer

56

144270

THERMOCOUPLE -Not for Spider-

57

144036

CLIP

59

63006500

UPPER REAR SHIELD

60

63632900

BUMPER PROTECTION SHIELD

60

63547900

BUMPER PROTECTION SHIELD
