No

Kod

Parça Adı

0

144508

COMPLETE R.H SUCTION MANIFOLD

1

144509

COMPLETE LH SUCTION MANIFOLD

1

RH SUCTION MANIFOLD

RH SUCTION MANIFOLD

2

LH SUCTION MANIFOLD

LH SUCTION MANIFOLD

3

138029

GASKET

4

13525770

THREADED INSERT

5

115147

RUBBER PIPE

6

11500324

STUD BOLT

7

11197774

Washer

36

101239

CAP NUT

9

100424

BALL JOINT

10

66535800

SCREW

11

12601374

Washer

12

10450690

BRACKET WITH SHEATH

13

136815

PNEUMATIC CAPSULE

14

11001721

STUD

18

319201

FUEL FILLER PIPE ASSEMBLY

16

14496324

WASHER

17

137277

STUD

19

10730021

WASHER

20

137135

LEVER

56

137271

BUSHING

58

10794501

SPLIT PIN

57

14496204

WASHER

24

137270

R. H. THREADED TIE ROD

25

10791114

L.H. THREADED NUT

26

137273

ADJUSTMENT SLEEVE

27

10794011

NUT

28

137276

L. H. THREADED TIE ROD

29

10450590

BRACKET

30

146877

COMPLETE SUCTION MANIFOLDS COVER

30

113636

UNION

31

SUCTION MANIFOLDS COVER

SUCTION MANIFOLDS COVER

32

138045

GASKET -Valid for USA and CDN-

33

11500524

STUD BOLT

34

13541124

STUD BOLT

35

10519424

WASHER

59

141563

THREADED PLUG

38

128016

CONNECTOR

39

142507

UNION

40

117348

THREADED UNION

41

142511

UNION

42

136922

BUSHING

43

138169

SPRING

44

138173

BUTTERFLY CONTROL SHAFT

45

137280

AIR ADJUSTTING THROTTLE

46

136923

SCREW

47

139373

PROTECTION BOOT

48

129269

SEAL RING

49

136921

WASHER

50

11065676

Seeger Ring

51

154270

THROTTLE CONTROL LEVER

52

136924

SCREW

53

111704

SOLENOID VALVE

54

128907

Pipe from cut-off to solenoid valve

55

113566

SAFETY PLATE

60

14326150

CAP

61

137126

WASHER

62

14059311

NUT

64

155871

AIR FILTER
