No

Kod

Parça Adı

-

112130

DITTO THICKNESS mm. 1.2

-

112131

DITTO THICKNESS mm. 1.3

-

112128

DITTO THICKNESS mm. 1.0

-

112129

DITTO THICKNESS mm. 1.1

8

147690

COMPLETE PEDAL SUPPORT

1

157268

CLUTCH PEDAL

2

162536

CLUTCH PEDAL DRILLED PLATE

3

103163

SELF-LUBRICATING BUSHING

4

109407

BALL-JOINT

5

101305

SPRING

6

187014

PEDAL ADJUSTER SCREW

33

16102314

NUT

9

129615

GASKET

49

141521

CLIP

11

14441324

SCREW

46

14039614

NUT

13

145034

CLUTCH CONTROL INTERMEDIATE PIPE

14

129612

SPRING ANCHOR PIN

15

11500124

STUD BOLT

16

129613

PEDALS SUPPORT PIN

17

101314

BUSHING

18

112153

BUSHING

19

112125

SPACER WASHER

20

112127

DITTO THICKNESS mm. 0.9

21

11066676

FLEXIBLE RING

34

13516824

STUD BOLT

23

104030

Nut

24

14499421

WASHER

25

62877200

PEDAL SUPPORT PROTECTION

26

62694400

GASKET

28

12646604

WASHER

29

15925601

SCREW

47

12639724

Washer

32

175211

Clutch master cylinder

35

14040711

NUT

36

12601374

Washer

37

10248271

FORK FOR CLUTCH LEVER

38

16043634

SCREW

39

147985

NUT

40

151845

PIPE FROM CLUTCH PUMP TO

41

157934

SCREW COLLAR

42

162892

PIPE FROM PUMP TO UNION

43

105369

CABLE GROMMET

44

141522

CLIP

48

139375

2-WAY UNION

50

184497

CONNECTOR

51

175189

SEAT RING
