No

Kod

Parça Adı

-

64113800

DASHBOARD RH UPPER LATERAL FIXING BRACKET

-

64510700

AIR OUTLET CENTRAL PLATE

-

64510500

AIR OUTLET LH LATERAL PLATE

33

170934

PLATE FOR INSTRUMENTS

-

170935

PLATE FOR INSTRUMENTS

-

10977724

SCREW

-

644324

DASH PANEL (leather)

-

644467

LINING

-

644464

COVERED INSTRUMENTS PANEL

-

62175700

R.H. TWEETER FIXING BRACKET

-

644448

COVERED L.H. LOWER INSERT

-

641178

L.H. LOWER UPHOLSTERY

-

644451

L.H. LOWER UPHOLSTERY

-

644456

COVERED R.H. LOWER INSERT

-

100992

R.H. LOWER UPHOLSTERY

-

644459

R.H. LOWER UPHOLSTERY

-

648847

UPHOLSTERED DASHBOARD UPPER FRAMEWORK

-

641183

UPPER LINING

-

644439

UPPER LINING

1

644777

UPHOLSTERED DASHBOARD UPPER FRAMEWORK

2

644782

COVERED R.H. LOWER INSERT

3

644792

COVERED L.H. LOWER INSERT

4

62175800

L.H. TWEETER FIXING BRACKET

5

13832101

NUT

50

12648925

WASHER

7

15785101

SCREW

8

14115980

BLOCK-Valid for USA-

9

64263100

COMPLETE BRACKET

10

10977524

SCREW

13

11197774

Washer

12

14039614

NUT

14

12643724

WASHER

15

62200500

AIR DUCTING GASKET

16

62188000

AIR CONVEYOR GASKET

17

62139700

INSTRUMENTS PANEL FIXING PLATE

18

62139800

ANTI VIBRATIONS

19

15896470

NUT

20

12601174

Washer

21

14496324

WASHER

22

62185800

UNDER DASHBOARD AIR DUCTING

23

641120

COVERED INSTRUMENTS PANEL

24

15687775

SCREW

25

10519278

WASHER

26

14115885

Block

27

13836324

SCREW

28

62186800

AIR OUTLET PLATE

29

62880800

AIR OUTLET GRID SHIELD

30

63291400

SCREW -Not for GD-

31

63622400

WASHER

32

62880900

SCREW COVER PLATE

34

15908606

SCREW

35

14115580

BLOCK

36

12612207

WASHER -Valid for USA-

37

15692178

SCREW

38

64426700

PLATE FOR RADIO HOUSING

39

62993400

CLIP

40

16101714

NUT

41

10615174

WASHER -Not for GTS-

42

232649

CLIP

43

64493700

F 355 MARK

44

88074800

Clip

45

64113600

AIR OUTLET CENTRAL PLATE

46

64113300

AIR OUTLET RH LATERAL PLATE

47

15902670

SCREW -Valid for USA-

48

64113900

DASHBOARD LH UPPER LATERAL FIXING BRACKET

49

360500980

BI-ADHESIVE TAPE

51

14624687

PLUG

52

13831801

NUT

53

12638124

Washer

54

60609700

RIVET

55

12599274

WASHER
