No

Kod

Parça Adı

-

64401000

CONTROL STATION SUPPORT BRACKET

-

64536900

DELIVERY RUBBER PIPE

-

64495100

RUBBER PIPE TO COCK

-

60679700

CABLE GROMMET

-

62189700

L.H. AIR DELIVERY TUBE

-

62189600

R.H. AIR DELIVERY TUBE

-

62189500

AIR DIFFUSER

-

64320200

L.H Air Outlet

1

65353400

COMPLETE EVAPORATOR SET

-

65365900

COMPLETE EVAPORATOR SET

2

63307200

POWER UNIT

3

65518600

EXPANSION VALVE

4

70000900

COMPLETE WATER PUMP KIT

5

63306400

COCK WITH BRACKET

6

63306900

AIR INTAKE SENSOR

7

63306700

LID ACTUATOR

8

62341000

EVAPORATOR TEMPERATURE SENSOR

9

63306600

SENSOR RETAINING CLIP

10

160893

AIR CONDITIONING CABLES ASSEMBLY

11

63306800

MICRORELAY

12

63307100

TIMING ACTUATOR

13

63307000

TREATED AIR SENSOR

14

64320000

CENTRAL OPENING

15

64046400

AIR DIFFUSER

16

62188100

GASKET

17

64320100

R.H Air Outlet

18

62188200

RH PIPE/DIFFUSOR GASKET

19

62188300

LH PIPE/DIFFUSOR GASKET

20

12644424

Washer

21

127494

Washer

22

10977524

SCREW

23

63963100

R.H. AIR DELIVERY TUBE

24

62679200

RH TUBE /AIR DIFFUSER GASKET

25

62679000

LH TUBE/AIR DIFFUSOR GASKET

26

63963200

L.H. AIR DELIVERY TUBE

27

14201980

Block

28

12638124

Washer

29

15688170

SCREW

30

63562900

EVAPORATOR/TANK PIPE

31

63563000

WATER PUMP/EVAPORATOR PUMP PIPE

32

262109

COLLAR

33

10398780

CABLE GROMMET

34

62928200

TAMBOUR SEAT GASKET

35

62656000

BELLOWS FOR CONDENSATE VENT

36

62658800

CLIP

37

14039614

NUT

38

62659400

RUBBER PIPE TO COCK

39

63306300

PIPE FROM PUMP TO EVAPORATOR

40

63311700

PIPE FROM EVAPORATOR TO COCK

41

64536500

DELIVERY RUBBER PIPE

42

62928000

UPPER GASKET

43

62928100

TAMBOUR PROFILE GASKET

44

63234200

SCREW

45

127496

Washer

46

64324800

A.C. ELECTRONIC CONTROL STATION

47

64281100

CONTROL STATION SUPPORT BRACKET

48

13272011

SCREW

49

14496204

WASHER

50

64530800

GASKET

51

12639724

Washer

52

168220

Screw Collar -Applicable for CINA, USA, CDN, J- -Applicable from Ass. No. 90609- -Applicable for DCT gearbox- -No longer supplied- -Replaced by 268210-
