No

Kod

Parça Adı

-

175834

F1 GEARBOX SYSTEM COMPONENTS KIT

2

177687

COMPLETE HYDRAULIC ACTUATOR

3

167946

COUPLING BALL JOINT

4

170767

SCREW

5

103493

WASHER

13

147985

NUT

7

169221

THREADED PIN

8

169219

ACTUATOR SUPPORT

9

169222

BALL JOINT

10

126980

WASHER

12

84653800

WASHER

14

168523

SHIELD FOR ACTUATOR PROTECTION

15

12637824

WASHER

16

12578011

NUT

17

166935

CLIP

18

11181474

WASHER

19

10444521

SCREW

32

111644

UNION

48

10261060

Gasket

22

168472

PIPE (EV4)

23

168470

PIPE (EV3)

24

168474

PIPE (EV5)

25

168468

PIPE (EV2)

26

168466

PIPE (EV1)

27

168525

PROTECTION SHEATH

28

124034

BRACKET WITH SHEATH

29

10519424

WASHER

45

14039614

NUT

31

175833

PIPE FROM PUMP TO BLOCK

34

175667

BLOCK

37

171630

UNION-Valid for F1-

38

152954

BLEED SCREW

39

152955

PROTECTIVE CAP

49

10284460

GASKET

42

70001184

FEMALE COUPLING -Not as spare part- -Replaced by 210469-

43

174421

PIPE FROM BLOCK TO GEARBOX

44

10441790

BRACKET WITH SHEATH

46

12639724

Washer

47

171454

PIPE UNION

50

172447

UNION

51

210468

QUICK MALE COUPLING

52

171602

QUICK FEMALE COUPLING

53

174317

UNION

54

14164274

PIN
