No

Kod

Parça Adı

26

185130

DELIVERY PUMP BODY WITH STUD BOLTS

25

185129

RECOVERY PUMP BODY WITH STUD BOLTS

-

181819

COMPLETE OIL SUMP

1

178413

OIL SUMP

2

173623

ANTI-SHAKING OIL PANEL

3

14040711

NUT

4

84653800

WASHER

5

13516524

STUD BOLT

6

11307021

Screw

7

11190574

WASHER

8

132876

NUT -As an alternative-

9

223577

THREADED INSERT

10

307477

THREADED PLUG

11

10261860

Gasket

29

14306424

SCREW

28

11198074

WASHER

14

132462

DRIVEN GEAR

15

185577

CHAIN TIGHTENER

16

169594

STUD

17

179938

STOP PLATE

18

12646604

WASHER

80

11197774

Washer

20

10902224

SCREW

21

171960

WASHER

22

11065474

FLEXIBLE RING

23

145326

BUSHING

24

133089

OIL PUMP CONTROL CHAIN

27

133939

O.R. GASKET

47

13540824

STUD BOLT

79

14039614

NUT

32

133842

STUD

33

133843

STUD

34

132458

DRIVING GEAR

35

132460

DRIVEN GEAR

36

109309

JOINT

37

132436

RECOVERY PUMP COVER

53

12604270

WASHER

40

121306

BALL

41

109980

SPRING FOR BALL

42

196077

SPACER

43

11057876

SEEGER RING

44

102704

CENTRING DOWEL

45

102725

CENTRING DOWEL

46

231629

SCREW

48

181862

DRIVEN GEAR

49

132454

DRIVING GEAR

50

13541024

STUD BOLT

51

10205820

Feather key

52

132434

FRONT COVER

55

176222

RECOVERY SUCTION PIPE

56

122429

Oil Filter

57

103944

Sealing ring

59

136039

FIXED TENSION

61

10902424

Screw

62

133938

O-Ring

63

11000824

Stud -Q.ty 4 for USA-

64

191973

COMPLETE MULTIPLE UNION

65

137192

O-RING

66

11199274

WASHER

67

10519378

WASHER

68

15896470

NUT

69

129324

REGISTER

70

177908

OUTER SPRING

71

10263360

Gasket

72

177423

OIL PRESSURE VALVE CAP

73

177909

INNER SPRING

74

179222

SCREW

75

127494

Washer

76

12644424

Washer

77

177130

GEARBOX OIL SUCTION FAN

78

11500224

STUD BOLT

81

177549

O.R. GASKET

82

177550

O.R. GASKET

83

104628

GEARBOX THERMISTOR

84

104535

O.R. GASKET
