No

Kod

Parça Adı

1

194105

WATER PUMP BODY

2

13525470

THREADED INSERT

3

171926

THERMOSTATIC VALVE COVER

4

137873

Gasket

5

149279

O-Ring

6

183758

Thermostat

7

231617

Screw

43

11197774

Washer

9

132349

CONNECTOR

10

10297760

Gasket

11

176045

WATER PUMP ROTOR

12

100436

BLIND NUT

13

84653800

WASHER

14

13540924

STUD BOLT

15

176173

WATER PUMP COVER

16

137868

O-Ring

17

183759

Seal Ring

42

14039614

NUT

20

143742

BEARING WITH SHAFT

21

10202320

Disc Tab

22

11059976

SEEGER RING

23

177207

WATER PUMP CONTROL PULLEY

24

12646821

Washer

25

102742

Nut

26

106227

Fitting

27

176046

BUSHING FOR BYPASS

28

176047

SPRING FOR BYPASS

29

147278

O-Ring

30

176048

CAP FOR BYPASS SPRING

31

11058376

SEEGER RING

32

180846

Water-Oil Heat Exchanger

33

187173

SLEEVE

34

153430

Clamp - D. 85 mm.-

35

13000790

Screw Collar

36

101044

O.R. Gasket

37

180137

Temperature Sensor

38

10298460

Gasket

39

9162535

THREADED PLUG

40

201446

Water Pump and Generator Control Belt

41

179748

COMPLETE WATER OUTLET MANIFOLD

44

141332

GASKET

45

180296

SMALL PLATE

46

179698

BELT TIGHTENING BEARING

47

15970921

SCREW

48

11190574

WASHER

49

14302824

SCREW

50

11198074

WASHER
