No

Kod

Parça Adı

-

66329000

CUSHION WIRING HARNESS, PASSENGER SIDE

-

66329200

RH SEAT BUTTON PANEL

-

66324600

RH CLIP

-

66326100

BOWDEN CABLE SHEATH

-

66090400

RH GUIDE COVER

-

66327700

REAR FASTENER BUSHING

-

66327300

LH GUIDE ASSEMBLY

1

66327200

RH GUIDE ASSEMBLY

2

66323500

UPPER PLATE

3

66327100

SCREW

4

66327900

SCREW

5

66327500

COMPLETE SCREW

6

66327600

FRONT FASTENER BUSHING

7

66090500

LH GUIDE COVER

8

166168

REAR PLATE

9

66328000

CONNECTOR

10

66326000

BACKREST BOLSTER ADJUSTMENT BOWDEN CABLE

11

66374500

ELECTRIC LUMBAR SUPPORT ADJUSTMENT MECHANISM

12

66328400

SCREW

13

663248

COMPLETE SADDLE

14

66324700

CLIP

15

66370200

LH CLIP

16

66324100

BACKREST BACKING SHELL TRIM

17

66324500

SEAT HOOK LEVER

18

66324400

FIXING PLATE

19

66324300

CLIP

20

66324200

SEAT RELEASE CABLE

21

66328800

COMPLETE CONNECTOR BAR

22

66328700

FASTENER RING

23

66327800

BACKREST ADJUSTMENT MOTOR

24

66328500

FASTENER KIT

25

66329300

LH SEAT BUTTON PANEL

26

66329400

SCREW

27

66329500

NUT

28

66329100

BACKREST WIRING HARNESS

29

66328900

CUSHION WIRING HARNESS, DRIVER SIDE

30

65917500

SCREW

31

12601474

WASHER
