No

Kod

Parça Adı

1

197150

HEAT EXCHANGER

2

322664

GASKET

3

210388

CONNECTORS MOUNTING BRACKET

4

149707

SHIM

5

177576

CABLE GROMMET

6

231622

SCREW

7

231621

Screw

8

231620

Screw

13

11197774

Washer

10

247146

GASKET

11

202251

BRACKET

12

231617

Screw

14

192327

CONNECTOR

15

10284460

GASKET

16

211844

VENT PIPE

17

195351

OIL PIPE FROM ENGINE TO SEPARATOR

17

225937

OIL PIPE FROM ENGINE TO SEPARATOR

18

216061

WATER-OIL SEPARATOR

18

225960

WATER-OIL SEPARATOR

18

216066

WATER-OIL SEPARATOR

18

226035

WATER-OIL SEPARATOR

19

254573

TANK CAP

20

211634

GASKET

21

176388

Gasket

22

13517124

STUD BOLT

23

147985

NUT

24

12601374

Washer

25

211813

RH BREATHER PIPE

25

223220

RH BREATHER PIPE

26

211814

LH BREATHER PIPE

26

223221

LH BREATHER PIPE

27

177996

CLAMP

28

262109

COLLAR

29

216063

RH VAPOUR INTAKE PIPE

29

216068

RH VAPOUR INTAKE PIPE

30

216064

LH VAPOUR INTAKE PIPE

30

216069

LH VAPOUR INTAKE PIPE

31

195330

RUBBER PIPE

32

258855

THREE-WAY UNION

33

159539

RUBBER PIPE

34

10440990

BRACKET WITH SHEATH

35

13432070

Collar for Hose Union
