No

Kod

Parça Adı

-

64374000

DELIVERY TUBE FROM ENGINE TO PUMP - L=450mm

-

65486100

DELIVERY TUBE FROM WATER PUMP WATER PUMP

-

65486200

RETURN TUBE FROM HEATER TO VALVE

-

64980200

HOSE FROM PIPE TO EVAPORATOR

-

64980100

HOSE FROM EVAPORATOR TO PIPE

13

70000900

COMPLETE WATER PUMP KIT

1

165563

AC CONDENSER

2

14778814

SCREW

4

65424800

SCREW COLLAR

37

14039614

NUT

6

64827500

PIPE FROM CONDENSER TO FILTER

7

64827400

PIPE FROM COMPRESSOR TO CONDENSER

8

64799500

DEHYDRATOR FILTER WITH PRESSURE SWITCH

9

285553

VIBRATION DAMPER

10

63994900

BRACKET FOR PUMP -Not as spare part- -Replaced by 69966100-

12

10519424

WASHER

14

64827300

PIPE FROM HOSE TO COMPRESSOR

15

64791200

HOSE FROM EVAPORATOR TO PIPE

16

61712500

Bracket with Sheath

18

64827600

PIPE FROM DEHYDRATOR FILTER TO HOSE

19

64791300

HOSE FROM PIPE TO EVAPORATOR

20

65485800

DELIVERY TUBE FROM WATER PUMP

21

65485900

RETURN TUBE FROM HEATER TO VALVE

22

61079000

ELECTRO-MAGNETIC VALVE

39

319201

FUEL FILLER PIPE ASSEMBLY

24

103549

Cable Grommet

25

103550

Spacer bush -Only for

40

12638124

Washer

27

64281500

UPPER FLANGE

28

63961800

RUBBER PIPE-HOLDER

29

63940200

DELIVERY TUBE FROM ENGINE TO PUMP - L=1050mm

30

61712600

BRACKET WITH SHEATH

32

10902424

Screw

51

127494

Washer

34

12643724

WASHER

35

64980400

PIPE FROM HOSE TO COMPRESSOR

36

64980300

PIPE FROM DHEYDRATOR FILTER TO HOSE

38

63961900

FRAME FOR PIPE BUSHING

41

10459087

CABLE GROMMET

42

66374400

PRESSURE SWITCH

43

165562

BRACKET

44

165136

SCREW

45

165560

BRACKET

46

165137

SCREW

47

168068

L.H. LOWER BRACKET

48

165561

L.H. UPPER BRACKET

49

156989

SMALL PLATE

50

12646604

WASHER
