No

Kod

Parça Adı

22

159120

PIPE FROM REGULATOR TO SLEEVE

19

159831

L.H. SLEEVE

18

159830

R.H. SLEEVE

5

153196

COMPLETE SUCTION MANIFOLDS COVER

-

173520

COMPLETE SUCTION MANIFOLDS

1

153195

COMPLETE SUCTION MANIFOLDS

2

154245

END MANIFOLD

3

13525570

THREADED INSERT

10

128016

CONNECTOR

6

143286

UNION

7

13541224

STUD BOLT

9

141563

THREADED PLUG

11

154562

Gasket

12

156828

SCREW

29

11197774

Washer

14

148836

GASKET

15

14039614

NUT

17

154754

BRACKET

20

13001190

COLLAR

21

142432

REGULATOR FOR IDLE ADJUSTMENT

23

171759

PIPE FROM REGULATOR TO PLENUM CHAMBER

24

13000490

Screw Collar

25

148832

COMPLETE RH THROTTLE HOLDER

26

148833

COMPLETE LH THROTTLE HOLDER

27

142934

O.R. Gasket

28

101239

CAP NUT

30

158170

POTENTIOMETER FOR THROTTLE VALVE

31

10444521

SCREW

32

11181474

WASHER

33

178200

PUSH-PULL CABLE

38

15896470

NUT

41

111530

FEMALE BALL JOINT

36

319201

FUEL FILLER PIPE ASSEMBLY

37

14496324

WASHER

39

11088076

FLEXIBLE RING

40

12626024

WASHER

42

173999

BALL-JOINT HEAD

43

174001

SPRING CLIP

44

16102314

NUT
