No

Kod

Parça Adı

-

65669400

L.H. REINFORCEMENT

-

63893000

L.H. AIR PROTECTION PLATE

-

63748000

L.H. LOWER PLATE

-

63758900

L.H. SMALL BLOCK

-

170010

BLANK KEY

45

177879

BRACKET FOR MICRO-SWITCH FIXING

-

65424400

COMPLETE HANDLE SECONDARY LEVER

-

65100500

HANDLE PRIMARY LEVER

-

63895300

LH COLUMN

-

63888500

L.H. TIE ROD

-

65808300

LH COMPLETE OUTER DOOR HANDLE

-

63180400

LH COMPLETE LOCK CONTROL BLOCK

-

63497500

L.H. COMPLETE DOOR LOCK

-

63188800

L.H. LOWER MOBILE HINGE

-

63189400

L.H. UPPER MOBILE HINGE

-

162546

DOORS LOCKS SET COMPLETE

1

65195200

TIE-ROD

-

63724900

LH INNER HANDLE FOR DOOR OPENING

2

63487400

CENTRALIZED LOCKING DEVICE

3

63724800

RH INNER HANDLE FOR DOOR OPENING

4

63188700

R.H. LOWER MOBILE HINGE

5

65404200

THICKNESS mm. 8-10

6

11087776

SNAP RING

7

63189300

R.H. UPPER MOBILE HINGE

8

63747100

THICKNESS mm. 8-10

9

13839224

SCREW

10

65274600 / 10903280

PIN

11

63168000

R.H. TIE ROD

12

65808200

RH COMPLETE OUTER DOOR HANDLE

13

63180300

RH COMPLETE LOCK CONTROL BLOCK

14

63497400

R.H. COMPLETE DOOR LOCK

15

63895200

RH COLUMN

16

63157000

DOOR CLOSING STRIKER

17

63877300

PLATE

18

63859200

MICROSWITCH

19

63859800

OUTER DOOR HANDLE MICRO-SWITCH

20

63189600

BUSHING

21

63189700

PIN

22

63724400

INNER DOOR HANDLE MICRO-SWITCH

23

64203800

WASHER

24

11087476

SNAP RING

25

13299477

Screw

56

53451371

TIE ROD RETAINING CLIP

27

63722500

SAFETY LOCK FRONT ROD FOR DOOR

28

63723100

HANDLE CONNECTION FRONT ROD

29

10794011

NUT

30

63402100

ADJUSTMENT SLEEVE

31

10791114

L.H. THREADED NUT

32

63722600

SAFETY LOCK REAR ROD FOR DOOR

33

63723200

HANDLE CONNECTION REAR ROD

34

63167400

HANDLE PRIMARY LEVER

35

63167800

SEFETY DEVICE PRIMARY LEVER

36

63167900

SEFETY DEVICE SECONDARY LEVER

37

63168600

SAFETY DEVICE TRANSMISSION PIN

38

63167500

HANDLE SECONDARY LEVER

39

63158500

HANDLE TRANSMISSION PIN

40

14441582

SCREW

41

62794700

WASHER

42

13276077

SCREW

43

13550277

WASHER

44

14442434

SCREW

46

155978

CLIP

47

64215300

CLIP

48

62947900

SCREW

49

16101777

NUT

50

63158010

OUTER HANDLE SUPPORT

51

63772500

TIE ROD

52

62794000

JOINT

53

63179700

FIXING CLIP

54

63758800

R.H. SMALL BLOCK

55

15643975

SCREW

57

64074200

RETUTN SPRING FOR TIE ROD

58

164089

BLANK KEY

59

10903280

Screw

60

14039614

NUT

61

65582700

SPRING PIN

62

63852610

HANDLE MOVABLE PART

63

65321600

SMALL PLATE

64

65669300

R.H. REINFORCEMENT

65

63893100

R.H. AIR PROTECTION PLATE

66

63747900

R.H. LOWER PLATE
