No

Kod

Parça Adı

-

178751

R.H. BRACKET

-

175674

L.H. BRACKET

-

179857

CABLES FOR RH MAIN BEARINGS CONNECTION

-

177183

CABLES FOR RH MAIN BEARINGS CONNECTION

-

179862

CABLES FOR RH MAIN BEARINGS CONNECTION

-

180506

CABLES FOR RH MAIN BEARINGS CONNECTION

-

179858

CABLES FOR LH MAIN BEARINGS CONNECTION

-

177184

CABLES FOR LH MAIN BEARINGS CONNECTION

-

179863

CABLES FOR LH MAIN BEARINGS CONNECTION

-

180507

CABLES FOR LH MAIN BEARINGS CONNECTION

-

174495

CABLES FOR RH MAIN BEARINGS CONNECTION

-

122126

RUBBER PIPE FROM SECONDARY AIR SYSTEM PIPE TO SOLENOID VALVE

-

175792

PROGRAMMED ELECTRONIC CONTROL STATION

-

175797

PROGRAMMED ELECTRONIC CONTROL STATION

-

181680

PROGRAMMED ELECTRONIC CONTROL STATION

-

175807

PROGRAMMED ELECTRONIC CONTROL STATION

-

175793

PROGRAMMED ELECTRONIC CONTROL STATION

-

175795

PROGRAMMED ELECTRONIC CONTROL STATION

-

181679

PROGRAMMED ELECTRONIC CONTROL STATION

-

175805

PROGRAMMED ELECTRONIC CONTROL STATION

-

175789

PROGRAMMED ELECTRONIC CONTROL STATION

1

155327

BRACKET

2

16043124

SCREW

3

127496

Washer

4

175788

PROGRAMMED ELECTRONIC CONTROL STATION

5

162530

AIR FLOW METER

6

173751

R.H. INJECTORS COMPLETE TUBE

7

173745

L.H. INJECTORS COMPLETE TUBE

8

248334

SCREW

9

11197774

Washer

10

162613

ELECTRO-INJECTOR

11

133902

O-Ring

12

167321

PRESSURE REGULATOR

13

152211

SEAL RING

14

118901

RUBBER PIPE

15

174496

CABLES FOR LH MAIN BEARINGS CONNECTION

16

291225

BRACKET WITH SHEATH

17

168529

INJECTORS CONNECTION CABLES

18

145545

SPRINGS

20

10418601

BRACKET WITH SHEATH

34

10977524

SCREW

22

12639724

Washer

33

127494

Washer

24

154772

BRACKET FOR CABLES FIXING

25

139465

BELLOWS FOR CABLE

26

144763

INJECTOR RETAINING SPRING

27

172763

SCREW

29

14039614

NUT

32

10519424

WASHER

35

319201

FUEL FILLER PIPE ASSEMBLY

36

12637824

WASHER

37

178750

R.H. BRACKET

38

175683

ABS CONTROL UNIT FIXING BRACKET

39

175675

L.H. BRACKET
