No

Kod

Parça Adı

-

112131

DITTO THICKNESS mm. 1.3

-

112127

DITTO THICKNESS mm. 0.9

-

112128

DITTO THICKNESS mm. 1.0

-

112129

DITTO THICKNESS mm. 1.1

-

112130

DITTO THICKNESS mm. 1.2

-

113835

WASHER

-

113836

WASHER

-

10007871

FORK FOR BRAKE LEVER

-

151979

PEDALS SUPPORT PIN

-

113833

WASHER

-

113834

WASHER

-

179933

COMPLETE PEDAL SUPPORT

-

179934

COMPLETE PEDAL SUPPORT

-

176296

PEDAL SUPPORT

1

176297

PEDAL SUPPORT

4

13525770

THREADED INSERT

3

13525470

THREADED INSERT

5

13516824

STUD BOLT

6

11500224

STUD BOLT

7

133555

PUSHBUTTON SWITCH

8

152310

SMALL PLATE

69

14039614

NUT

10

12646604

WASHER

11

176275

BRAKE PEDAL

66

103163

SELF-LUBRICATING BUSHING

16

109407

BALL-JOINT

14

132819

Pedal protection

15

176294

CLUTCH PEDAL

17

112125

SPACER WASHER

18

132818

Pedal protection

19

176290

PEDALS SUPPORT PIN

20

10902224

SCREW

21

11197774

Washer

23

106083

WASHER

24

101305

SPRING

25

164393

FORK FOR CLUTCH LEVER

26

176291

FORK FOR BRAKE LEVER

27

16043634

SCREW

28

147985

NUT

36

16102314

NUT

30

187014

PEDAL ADJUSTER SCREW

32

176300

ACCELERATOR PEDAL

33

101677

ROLLER BEARING

34

138219

CARRIER BUSH

35

123961

PEDAL ADJUSTEMENT PIN

37

176299

ACCELERATOR SUPPORT

38

10903621

SCREW

40

176330

GASKET

41

156123

ACCELERATOR CABLE

42

15896470

NUT

43

173999

BALL-JOINT HEAD

44

174001

SPRING CLIP

45

157557

PULLEY

46

152405

SUPPORT

47

231625

Screw

49

14499421

WASHER

63

127496

Washer

51

16043324

SCREW

56

104030

Nut

53

176298

BRAKE PEDAL

54

144237

PEDAL RUBBER

57

176281

BRAKE CONTROL LEVER

61

101314

BUSHING

59

171351

WASHER THINCKNESS mm. 0,8

60

11066676

FLEXIBLE RING

62

112153

BUSHING

64

15115721

SCREW

65

130926

SCREW

67

178812

BRACKET

68

103549

Cable Grommet

70

12644477

WASHER

71

178895

PROTECTION
