No

Kod

Parça Adı

-

179739

RUBBER PIPE FROM COOLING PIPE TO TANK

-

179519

RUBBER PIPE FROM TANK TO PUMP

-

154158

PIPE FROM 3-WAY UNION TO LHACCUMULATOR

-

154159

PIPE FROM ACCUMULATOR TO SHOCK ABSORBER

-

154161

RETURN PIPE

-

178675

PIPE FROM REAR UNION TO VALVE

-

154157

PIPE FROM 3-WAY UNION TO RHACCUMULATOR

-

178672

PIPE FROM HOSE TO UNION

-

178674

PIPE FROM FRONT UNION TO REAR UNION

-

178670

PIPE FROM HOSE TO UNION

-

176971

PIPE FROM HOSE TO TWO-WAY UNION

22

179048

VALVE AND UNION ASSEMBLY

10

181233

SPINDLE FOR FUEL TANK

-

180590

COMPLETE PLUG

3

180585

GASKET FOR PLUG

1

179185

FUEL TANK

2

180320

COPMLETE TANK PLUG

4

153887

PLUG

5

154090

OIL LEVEL INDICATOR ROD

6

11903111

OIL OUTLET PLUG

7

10260160

GASKET

28

103549

Cable Grommet

27

103550

Spacer bush -Only for

11

13539424

STUD BOLT

71

319201

FUEL FILLER PIPE ASSEMBLY

72

14496324

WASHER

14

154691

GASKET

15

153646

STUD

91

14039614

NUT

17

157100

PLATE

92

10519424

WASHER

19

154217

OIL FILTER

26

12643724

WASHER

23

10902834

SCREW

25

127494

Washer

29

169224

INTERMEDIATE BRACKET

30

10519224

Washer

31

62790300

Nut

32

175639

PIPE FROM HOSE TO TWO-WAY UNION

69

155215

R.H. TWO-WAY UNION

67

12639724

Washer

36

168749

PIPE FROM FRONT UNION TO REAR UNION

37

168750

PIPE FROM REAR UNION TO VALVE

38

154156

3-WAY UNION

41

168752

PIPE FROM 3-WAY UNION TO RHACCUMULATOR

42

168753

PIPE FROM 3-WAY UNION TO LH ACCUMULATOR

43

169624

PIPE FROM ACCUMULATOR TO SHOCK ABSORBER

44

277407

FUEL FILLER NECK PIPE

56

10280060

Gasket

46

168754

RETURN PIPE

47

155444

RETURN RUBBER PIPE

51

13432070

Collar for Hose Union

49

155447

INTERMEDIATE BUNDY TUBE

50

155443

RUBBER PIPE TO TANK

52

155442

RUBBER PIPE FROM TANK TO PUMP

53

13000490

Screw Collar

54

158693

ACCUMULATOR FOR ATTITUDE VARIATOR

55

155129

UNION

57

14664790

CAGE SCREW

60

154310

FILTRATE ACCELEROMETER

62

12646604

WASHER

63

155574

RUBBER PIPE FROM COOLING PIPE TO TANK

64

262109

COLLAR

65

10441790

BRACKET WITH SHEATH

68

168751

PIPE FROM VALVE TO UNION

70

162426

VALVE CONTROL LEVER

73

172567

PIN

74

162432

TIE ROD

75

162428

BALL JOINT SEAT

76

162429

BALL JOINT SEAT

77

10794014

NUT

78

10791114

L.H. THREADED NUT

83

10441290

BRACKET WITH SHEATH

80

11001224

Stud bolt

82

16286127

SCREW

85

180913

UNION

86

179086

BRACKET

87

291225

BRACKET WITH SHEATH

89

179319

RUBBER HOSE

90

10441690

BRACKET WITH SHEATH
