No

Kod

Parça Adı

-

199836

Water & Power Steering Belt

-

201456

BELT

50

175223

RUBBER HOSE

-

10450690

BRACKET WITH SHEATH

56

199834

Water & Power Steering Belt

-

201455

WATER AND HYDR. STEERING

46

13000790

Screw Collar

-

160833

PIPE CONNECTING WATER PUMP

-

142088

R.H. HEAD WATER MANIFOLD

-

160831

PIPE FROM DUCT

45

181599

RUBBER PIPE BETWEEN MANIFOLD AND WATER PUMP

-

176045

WATER PUMP ROTOR

8

183758

Thermostat

-

169924

PULLEY

-

182693

WATER PUMP BODY COMPLETED WITH STUDS

-

231617

Screw

3

231619

SCREW

-

184038

COMPLETE WATER PUMP

1

153199

WATER PUMP BODY COMPLETED WITH STUDS

-

183760

COMPLETE WATER PUMP

2

163952

THERMOSTAT VALVE COVER

48

11197774

Washer

5

130282

Connection for drain

6

10297760

Gasket

7

149279

O-Ring

9

166454

PULLEY (Ø 102)

10

102742

Nut

11

12647021

WASHER

12

10202320

Disc Tab

13

143742

BEARING WITH SHAFT

14

11059976

SEEGER RING

15

137873

Gasket

16

13540924

STUD BOLT

17

13525470

THREADED INSERT

18

183759

Seal Ring

19

137868

O-Ring

20

176173

WATER PUMP COVER

47

14039614

NUT

23

9162535

THREADED PLUG

24

141068

UNION

25

100436

BLIND NUT

26

84653800

WASHER

27

154542

WATER PUMP IMPELLER

28

14306424

SCREW

29

11193874

Washer

30

141250

O-Ring

31

162609

R.H. HEAD WATER MANIFOLD

32

13516724

STUD

33

125769

Water Temperature Transmitter

34

10298460

Gasket

35

143323

L.H. HEAD WATER MANIFOLD

36

141332

GASKET

37

154198

WATER OUTLET MANIFOLD CONNECTION DUCT

38

155093

CONNECTOR

39

148677

Water Temperature Transmitter

40

145661

BRACKET WITH SHEATH

41

160554

UNION -Valid till engine Nr. 36344-

42

12601374

Washer

43

103039

Sealing ring

44

142103

GASKET

49

154716

PIPE CONNECTING WATER PUMP

51

13000490

Screw Collar

52

10450490

BRACKET WITH SHEATH

53

16043224

SCREW

54

127496

Washer

55

147985

NUT

57

176046

BUSHING FOR BYPASS

58

176047

SPRING FOR BYPASS

59

176048

CAP FOR BYPASS SPRING

60

147278

O-Ring

61

11058376

SEEGER RING
