No

Kod

Parça Adı

1

271974

TUNNEL SUB-ASSEMBLY

2

271963

COMPL. RH HALF FLOOR PANEL

3

271962

COMPL. LH HALF FLOOR PANEL

4

277059

RH CENTRE SIDEWALL

5

277060

LH CENTRE SIDEWALL

6

83814500

FRONT RH ENDPIECE

7

83814600

FRONT LH ENDPIECE

8

83815000

REAR RH ENDPIECE

9

83814700

REAR LH ENDPIECE

10

249925

FRONT FASTENER BRACKET FOR RH FLANK

11

249924

FRONT FASTENER BRACKET FOR LH FLANK

12

242109

RH FLOOR LATERAL EXTRUSION

13

242108

LH FLOOR LATERAL EXTRUSION

14

245513

RH BRACE BETWEEN TORQUE BOX AND TUNNEL

15

245514

LH BRACE BETWEEN TORQUE BOX AND TUNNEL

16

248977

FRONT RH FLOOR ENDPIECE

17

248976

FRONT LH FLOOR ENDPIECE

18

246743

FRONT RH CROSS MEMBER

19

246742

FRONT LH CROSS MEMBER

20

270076

STAFFA FISSAGGIO PEDALE.ACCELERATORE

21

266935

LH SEAT GUIDE RAIL FASTENER

22

266933

REAR FASTENER BRACKET FOR LH

23

277061

SILL LINK CROSS MEMBER

24

264308

LOWER RH EXTRUSION

25

264309

LOWER LH EXTRUSION

26

266430

COMPLETE CENTRAL REAR FIREWA

27

266431

RH LATERAL PANEL

28

266432

LH LATERAL PANEL

29

276315

FUEL TANK CROSS MEMBER

30

269641

COMPL. RH LATERAL TUBULAR CR

31

269639

COMPL. LH LATERAL TUBULAR CR

32

254479

REAR FASTENER BRACKET FOR RH REAR FLANK

33

254478

REAR FASTENER BRACKET FOR LH REAR FLANK

34

255316

RH REAR PILLAR BRACE

35

255315

LH REAR PILLAR BRACE

36

264431

RH SUBFRAME LINK EXTRUSION

37

264310

LH SUBFRAME LINK EXTRUSION

38

272092

UPPER RH BELT JOINT CASTING

39

272091

UPPER LH BELT JOINT CASTING

40

255318

RH SUSPENSION CASTING BRACE

41

255317

LH SUSPENSION CASTING BRACE

42

269606

EXTERNAL RH UPPER DIAGONAL B

43

269605

EXTERNAL LH UPPER DIAGONAL B

44

271958

RH INTERNAL BOX MEMBER

45

271956

LH INTERNAL BOX MEMBER

46

264311

CASTING FOR REAR RH SHOCK TOWER.

47

264312

CASTING FOR REAR LH SHOCK TOWER.

48

295745

COMPL. ENGINE BUFFER

49

83242000

BATTERY MOUNTING FASTENER CO

50

311385

RH FUEL PIPE GUARD PLATE

51

311384

LH FUEL PIPE GUARD PLATE

52

81992500

COMPL. RH LATERAL IMPACT REINFORCEMENT

53

81992600

COMPL. LH LATERAL IMPACT REINFORCEMENT

54

271419

EXTERNAL RH TRUSS

55

271417

EXTERNAL LH TRUSS

56

271425

INTERNAL RH TRUSS

57

271422

INTERNAL LH TRUSS

58

83816100

A PILLAR FLANGE, FRONT RH ELEMENT

59

83816300

A PILLAR FLANGE, FRONT LH SECTION

60

83868900

RH BOX ELEMENT REINFORCEMENT

61

83869000

LH BOX ELEMENT REINFORCEMENT

62

83125100

LOWER SEAT BELT FASTENER BRA

63

83157400

INTERNAL REAR FASTENER PLATE

64

83277900

REAR SCREEN FASTENER BRACKET

65

83306100

UPPER CENTRAL WINDSCREEN FAS

66

83306200

UPPER LATERAL WINDSCREEN FAS

67

83306300

LATERAL WINDSCREEN FASTENER

68

83834700

RH LOWER LATERAL WINDSCREEN

68

83835000

LH LOWER LATERAL WINDSCREEN

69

83835100

LOWER CENTRAL WINDSCREEN FAS
