No

Kod

Parça Adı

1

268984

HEAT EXCHANGER OUTLET PIPE T

2

248225

GEARBOX OIL RETURN PIPE

18

254644

O-RING

4

253632

FORK

20

253465

SCREW

21

11198074

WASHER

7

282812

BRACKET

8

13543824

STUD BOLT

9

243396

FRONT RUBBER PILLORY BLOCK

10

243399

BUSHING

11

243398

PLATE

12

11625824

SCREW

12

11568224

SCREW

13

304575

BRACKET

14

13836424

SCREW

15

13046224

NUT

16

256689

OIL DELIVERY PIPE

17

260773

OIL RETURN PIPE

19

274609

FORK

22

276751

PIPE FROM GEARBOX TO HEAT EXCHANGER

23

269645

SHIM

24

184727

CONNECTOR

25

10261460

Gasket

26

240632

OIL HEAT EXCHANGER

27

275172

GEARBOX OIL BREATHER PIPE

28

11903811

PIPE UNION

29

10284460

GASKET

30

275169

RUBBER GEARBOX OIL BREATHER

31

13432070

Collar for Hose Union

32

258573

LIFT SYSTEM FILLING TANK

33

275170

TANK FASTENER BRACKET

34

11625624

SCREW

35

125380

WATER TEMPERATURE SENSOR

36

10441790

BRACKET WITH SHEATH

37

11568124

SCREW

38

275541

HEAT EXCHANGER PIPE RETAINER

39

84036100

RH GUARD BRACKET

39

84036000

LH GUARD BRACKET
