No

Kod

Parça Adı

1

67085100

Gas Filter

16

14039614

NUT

3

251649

CLIP

4

250318

CLIP

5

82886700

PIPE FROM CONDENSER TO DEHYDRATOR FILTER

5

82924000

PIPE FROM CONDENSER TO DEHYDRATOR FILTER

5

82916600

PIPE FROM CONDENSER TO DEHYDRATOR FILTER

6

83556400

HVAC FILTER PIPE

6

85075800

HVAC FILTER PIPE

7

82886900

HVAC PIPE-UNDERFLOOR

7

83208200

HVAC PIPE-UNDERFLOOR

7

82924100

HVAC PIPE-UNDERFLOOR

7

83193900

HVAC PIPE-UNDERFLOOR

7

82659500

HVAC PIPE-UNDERFLOOR

8

14040711

NUT

9

83194000

GAS RETURN PIPE

9

82890300

GAS RETURN PIPE

9

81647600

GAS RETURN PIPE

10

81851000

PIPE FROM UNDER FLOOR

11

82890400

PIPE FROM UNDER FLOOR

11

81503300

PIPE FROM UNDER FLOOR

12

83330500

PIPE FROM COMPRESSOR

12

81503200

PIPE FROM COMPRESSOR

13

14306724

SCREW

14

81647200

BRACKET

15

231617

Screw

17

10450490

BRACKET WITH SHEATH

18

11625624

SCREW

19

82949000

BRACKET

19

81620400

BRACKET

20

11612726

SCREW

21

80552400

PRESSURE TRANSDUCER

22

82913700

UNDERBODY GAS DELIVERY PIPE TO CONDENSER

22

82916700

UNDERBODY GAS DELIVERY PIPE TO CONDENSER

28

13837017

Screw

24

81767500

PILLORY BLOCK

25

82913600

GAS DELIVERY PIPE TO CONDENSER

26

10441290

BRACKET WITH SHEATH

27

248334

SCREW

29

82329900

CLIP

30

255515

PLUG

31

82155900

DEHYDRATOR FILTER BRACKET

31

82886600

DEHYDRATOR FILTER BRACKET

32

11625824

SCREW

35

67085300

O-RING

34

82068300

O.R. GASKET

36

67085400

O-RING

37

68392000

O-RING

38

68392100

O-RING

39

66309700

O-RING

40

68392700

O-RING

41

11198074

WASHER

42

66309500

O-RING

43

66309400

O-RING
