No

Kod

Parça Adı

1

104561

Union

2

122828

Sleeve

3

122829

Sleeve

4

168220

Screw Collar -Applicable for CINA, USA, CDN, J- -Applicable from Ass. No. 90609- -Applicable for DCT gearbox- -No longer supplied- -Replaced by 268210-

5

149786

L.H. cyl. head oil exhaust pipe

6

150193

Gasket

7

13525570

THREADED INSERT

66

10902424

Screw

9

11500224

STUD BOLT

10

127494

Washer

11

134041

NUT

12

146906

Hose from reservoir to pump

13

138149

CONNECTOR

14

144485

Gasket

15

146905

Hose from pump to radiator

16

146904

Hose from radiator to reservoir

17

106195

BRACKET WITH SHEATH

68

14039614

NUT

67

10519424

WASHER

20

125517

Oil reservoir

21

145623

TANK PLUG

22

14496524

Washer

53

11197774

Washer

24

139646

Oil dip stick

26

11500524

STUD BOLT

27

125473

Oil suction fan

28

125521

O-RING

29

100332

OIL FILTER

30

148676

OIL THERMISTOR -Valid for AUS-

31

107003

ELECTRIC TERMINAL COVER

34

293107

THREADED PLUG

35

138150

CONNECTOR

36

144487

GASKET

37

10261460

Gasket

38

107978

VIBRATION DAMPER

39

107979

STOP CAP

40

107980

SHIM

41

123029

Screw

42

154568

Oil radiator

43

102947

VIBRATION DAMPER

52

12643724

WASHER

46

149548

Bracket

47

16296924

SCREW

49

149533

Gasket

50

149339

Conveyor

51

10902521

SCREW

54

10397480

CABLE GROMMET

55

125708

SUPPORT PIN

56

108242

WASHER

57

122826

RH cylinder head oil exhaust port

58

149808

LH cylinder head oil exhaust port

59

150192

Gasket

60

123277

Temperature switch

61

140809

HOOD FOR ELECTROFAN

62

153431

COMPLETE ELECTROFAN

63

154223

Fan -Valid for CH-

64

154224

AIR CONVEYOR

65

154225

Motor -Valid for CH-

69

180585

GASKET FOR PLUG
