No

Kod

Parça Adı

1

186103

FUEL TANK

2

168238

COMPLETE FUEL LEVEL INDICATOR CONTROL

3

154802

GASKET

4

121435

RING NUT

5

181932

FILLER

6

174095

GASKET

7

13276470

SCREW

8

11197774

Washer

9

174093

FLANGE

10

226448

COMPLETE PLUG

11

223707

GASKET

12

181977

FILLER-TANK CONNECTING PIPE

13

10718670

Collar

14

182265

VENT PIPE FROM VAPOR SEPARATOR TO FILLER

15

13432070

Collar for Hose Union

16

125769

Water Temperature Transmitter

17

179321

GASKET

18

179851

RUBBER HOSE

19

262109

COLLAR

20

181936

RH VALVE COMPLETED WITH PIPING

21

181935

LH VALVE COMPLETED WITH PIPING

22

181692

FUEL TANK FASTENER

23

103447

PIN

26

264555

SPLIT PIN

25

213177

THREADED TIE-ROD

27

104030

Nut

28

62766300

Screw Clip

29

16286127

SCREW

30

12639724

Washer

31

127494

Washer

32

181931

DISAREATOR

33

196488

VALVE COMPLETED WITH PIPING

34

66766900

UNDER TANK SHIELD

35

10902424

Screw

36

12643724

WASHER

37

60659100

Nut With Cage

38

64783600

CAP

39

65084500

AIR DELIVERY TUBE TO TANK

40

13000790

Screw Collar

41

148045

FUEL DRAIN PLUG

42

123622

GASKET

43

195049

Gasket

44

62943200

RUBBER PROTECTION

45

14622387

CAP

46

156682

RUBBER THICKNESS

47

171163

PROTECTION SHEATH

48

183850

BRACKET

49

183387

RUBBER THICKNESS

50

183685

RUBBER THICKNESS

51

156679

RUBBER THICKNESS

52

184206

GROUND CABLE

53

13276477

SCREW

56

14039614

NUT

55

12648277

WASHER
