No

Kod

Parça Adı

-

178186

ACCELERATOR CABLE

41

178185

ACCELERATOR CABLE

-

170706

GASKET

-

113835

WASHER

-

113836

WASHER

-

113833

WASHER

-

113834

WASHER

-

170707

CLUTCH PEDAL

-

170761

CLUTCH PEDAL

11

172538

BRAKE PEDAL

-

170531

PEDAL SUPPORT

-

178879

COMPLETE PEDAL SUPPORT

-

149328

COMPLETE PEDAL SUPPORT

-

173938

COMPLETE PEDAL SUPPORT

1

162808

PEDAL SUPPORT

4

13525770

THREADED INSERT

3

13525470

THREADED INSERT

5

13516824

STUD BOLT

6

11500224

STUD BOLT

7

133555

PUSHBUTTON SWITCH

8

152310

SMALL PLATE

58

14039614

NUT

10

12646604

WASHER

17

103163

SELF-LUBRICATING BUSHING

16

109407

BALL-JOINT

14

163865

BRAKE PEDAL DRILLED PLATE

15

162807

CLUTCH PEDAL

18

163871

CLUTCH PEDAL DRILLED PLATE

19

129954

PEDALS SUPPORT PIN

20

10902224

SCREW

21

11197774

Washer

23

106083

WASHER

24

101305

SPRING

25

164393

FORK FOR CLUTCH LEVER

26

10248271

FORK FOR CLUTCH LEVER

27

16043634

SCREW

28

147985

NUT

36

16102314

NUT

30

187014

PEDAL ADJUSTER SCREW

32

170676

ACCELERATOR PEDAL

33

101677

ROLLER BEARING

34

138219

CARRIER BUSH

35

123961

PEDAL ADJUSTEMENT PIN

37

152328

ACCELERATOR SUPPORT

38

10903621

SCREW

40

164394

GASKET

42

15896470

NUT

43

173999

BALL-JOINT HEAD

44

174001

SPRING CLIP

45

157557

PULLEY

46

152405

SUPPORT

47

231625

Screw

49

14499421

WASHER

50

127496

Washer

51

16043324

SCREW

59

104030

Nut

53

14441324

SCREW

55

164037

ACCELERATOR PEDAL DRILLED PLATE

56

14440734

SCREW -M5X 16-

57

14058311

NUT

60

13276011

SCREW

61

14591687

Fastener Button

62

175190

SHEATH

63

175191

SLEEVE
