No

Kod

Parça Adı

-

65085800

R.H. GUIDE

-

64348900

RH SEAT OUTER ARTICULATED JOINT COVER

-

65088100

LH SEAT INNER ARTICULATED JOINT COVER

-

65089300

RH SEAT INNER ARTICULATED JOINT COVER

-

65089100

R.H. SEAT OUTER BRACKET

-

65088700

R.H. SEAT INNER BRACKET

-

64348500

R.H. SEAT BACK INNER ADJUSTER

-

64329300

R.H. SEAT BACK OUTER ADJUSTER

-

65088200

LH SEAT INNER TRANSMISSION COVER

-

64348600

SEAT R.H. TRANSMISSION COVER

-

65089400

RH SEAT INNER TRANSMISSION COVER

-

65087400

L.H. SEAT INNER BRACKET

-

65459500

SAFETY BELTS ASSEMBLY

-

65217600

R.H. BRACKET

-

64606000

L.H. lateral stuffing for pillow

-

64334700

R.H. lateral stuffing for pillow

-

64605900

R.H. lateral stuffing for pillow

-

65208400

SAFETY BELTS ASSEMBLY

-

64605600

SEAT BACK R.H. LATERAL FOAM

-

64679100

CUSHION UPPER CENTRAL FOAM

-

64605700

SEAT BACK L.H. LATERAL FOAM

-

64605400

SEAT BACK R.H. LATERAL FOAM

-

670403

SEAT LATERAL UPHOLSTERY

-

670404

SEAT LATERAL UPHOLSTERY

-

670405

SEAT CENTRAL UPHOLSTERY

-

670199

SEAT CENTRAL UPHOLSTERY

-

654999

R.H. FRONT SEAT "NARROW"

-

645320

CALF-REST COMPLETE UPHOLSTERY

-

643991

CUSHION COMPLETE LH LATERAL UPHOLSTERY

-

643348

CUSHION COMPLETE RH LATERAL UPHOLSTERY

-

654993

R.H. FRONT SEAT "LARGE"

-

654994

R.H. FRONT SEAT "LARGE"

-

654995

R.H. FRONT SEAT "NARROW"

-

654996

R.H. FRONT SEAT "NARROW"

-

654997

R.H. FRONT SEAT "NARROW"

-

654998

R.H. FRONT SEAT "NARROW"

-

654987

L.H. FRONT SEAT "NARROW"

-

654988

L.H. FRONT SEAT "NARROW"

-

654990

R.H. FRONT SEAT "LARGE"

-

654991

R.H. FRONT SEAT "LARGE"

-

654992

R.H. FRONT SEAT "LARGE"

-

654982

L.H. FRONT SEAT "LARGE"

-

654983

L.H. FRONT SEAT "LARGE"

-

654984

L.H. FRONT SEAT "NARROW"

-

654985

L.H. FRONT SEAT "NARROW"

-

654986

L.H. FRONT SEAT "NARROW"

-

654979

L.H. FRONT SEAT "LARGE"

-

654980

L.H. FRONT SEAT "LARGE"

-

654981

L.H. FRONT SEAT "LARGE"

1

65087100

SEAT BACK UPPER AND LATERAL FOAM

2

65194800

SEAT BACK CENTRAL FOAM

3

64605500

SEAT BACK L.H. LATERAL FOAM

4

64347800

Central stuffing upper pillow

5

64605800

Central stuffing lower pillow

6

65383300

CALF-REST FOAM

7

64399000

L.H. lateral stuffing for pillow

8

65194400

SAFETY BELTS ASSEMBLY

9

65217800

L.H. BRACKET

10

64347200

SEAT L.H. TRANSMISSION COVER

11

65087900

L.H. SEAT OUTER BRACKET

12

64346900

L.H. SEAT BACK INNER ADJUSTER

13

64328700

L.H. SEAT BACK OUTER ADJUSTER

14

64347400

LH SEAT OUTER ARTICULATED JOINT COVER

15

64331300

SEAT BACK ADJUSTMENT KNOB

16

64330800

PLUG FOR KNOB

17

64330700

ARTICULATED JOINT CONTROL PULLEY

18

64347100

PULLEYS CONNECTING BELT

19

64328200

PIN

20

64347000

SELF-LUBRICATING BUSHING

21

64347700

WASHER

22

64347600

ARTICULATED JOINT CONNECTION ROD

23

65086100

GUIDE CONTROL FORK

24

65085900

L.H. GUIDE

35

14306374

SCREW

40

63395300

ELASTIC PLATE

27

16160976

SNAP RING

28

65086000

STOP BRACKET

29

10977524

SCREW

30

160957

Washer

31

12644424

Washer

32

63929800

SCREW

33

13550405

WASHER

34

85692000

SCREW

39

40294308

SCREW

41

16043434

SCREW

43

84653800

WASHER
