No

Kod

Parça Adı

1

182614

FUEL TANK

2

181935

LH VALVE COMPLETED WITH PIPING

3

181936

RH VALVE COMPLETED WITH PIPING

4

196488

VALVE COMPLETED WITH PIPING

5

195049

Gasket

6

181932

FILLER

7

174095

GASKET

8

13276470

SCREW

9

11197774

Washer

10

174093

FLANGE

11

226444

COMPLETE PLUG

12

223707

GASKET

13

181977

FILLER-TANK CONNECTING PIPE

14

10718670

Collar

15

182265

VENT PIPE FROM VAPOR SEPARATOR TO FILLER

16

13432070

Collar for Hose Union

17

148045

FUEL DRAIN PLUG

18

123622

GASKET

19

179851

RUBBER HOSE

20

262109

COLLAR

21

13276477

SCREW

22

171163

PROTECTION SHEATH

23

196078

BRACKET

24

66849400

FUEL EXHAUST SEAL DOOR

46

14039614

NUT

26

12648277

WASHER

28

62766300

Screw Clip

29

16286127

SCREW

30

12639724

Washer

31

127494

Washer

32

181931

DISAREATOR

33

190154

COMPLETE RING -Valid for EU GS not F1 and

34

186172

CLIP

35

179137

FUEL PRESSURE SENSOR

36

122126

RUBBER PIPE FROM SECONDARY AIR SYSTEM PIPE TO SOLENOID VALVE

37

10977724

SCREW

38

12601174

Washer

39

12637824

WASHER

40

178430

FASTENER CLIP

41

291225

BRACKET WITH SHEATH

42

61712500

Bracket with Sheath

44

12643724

WASHER

45

172995

BRACKET WITH SHEATH

47

10519424

WASHER

48

67194500

GUARD
