Ferrari Yedek Parça - 612 Scaglietti Parts - LUBRICATION - OIL SUMP AND FILTERS
Parça Kodları
No
Kod
Parça Adı
-
172465
COMPLETE OIL SUMP
-
233823
COMPLETE OIL SUMP
1
165757
OIL SUMP
1
210737
OIL SUMP
2
12601374
Washer
3
147985
NUT
4
13971134
STUD BOLT
5
153423
STUD BOLT
6
13543424
STUD BOLT
7
13543624
STUD BOLT
8
100041
CENTRING DOWEL
9
13525770
THREADED INSERT
10
13541224
STUD BOLT
11
13525470
THREADED INSERT
12
145085
CONNECTOR
15
144485
Gasket
14
154602
OIL SUMP COVER
16
153903
OIL DRAIN PLUG
17
10280060
Gasket
18
13526570
THREADED INSERT
19
125308
OIL PICKUP FILTER
20
13540724
STUD BOLT
43
14039614
NUT
35
11197774
Washer
23
138149
CONNECTOR
24
141960
GASKET
27
156144
THREADED PLUG
28
10303460
Gasket
29
206166
Oil Filter Cartridge
30
141707
CONNECTOR
31
197596
MOUNTING
31
208782
MOUNTING
32
193478
PRESSURE TRANSMITTER
32
304074
Pressure Transmitter
33
132248
O-RING
34
14305324
SCREW
36
282753
COVER
39
13525870
THREADED INSERT
40
13525570
THREADED INSERT
41
167016
OIL BAFFLE PLATE
42
13540824
STUD BOLT
44
10519424
WASHER
45
142060
BRACKET
