No

Kod

Parça Adı

-

195408

COMPLETE F1 GEARBOX SYSTEM COMPONENT KIT

-

226556

COMPLETE F1 GEARBOX SYSTEM COMPONENT KIT

1

179143

ACCUMULATOR

2

980001156

PRESSURE SENSOR

3

179211

DUCT

4

179140

POWER UNIT

4

248412

POWER UNIT

5

248376

HP ACCUMULATOR PIPE KIT

6

248377

HP PUMP PIPE KIT

6

226496

PIPE FROM HYDRAULIC PUMP TO POWER UNIT

7

247223

ELECTRIC PUMP KIT

7

248087

ELECTRIC PUMP KIT

8

247225

INTAKE PIPE KIT

8

248308

INTAKE PIPE KIT

9

247226

OIL TANK KIT

10

247227

3-WAY PIPE KIT

11

248089

PROPORTIONAL PRESSURE VALVE

11

248351

PROPORTIONAL PRESSURE VALVE

12

248090

PROPORTIONAL FLOW VALVE

12

248352

PROPORTIONAL FLOW VALVE

13

248091

PROPORTIONAL FLOW VALVE

14

175283

Nut

15

162606

CLIP

16

10902224

SCREW

17

127494

Washer

18

231684

COMPLETE BREATHER PIPE

18

234328

COMPLETE BREATHER PIPE

19

10441890

BRACKET WITH SHEATH

20

10902424

Screw

47

11197774

Washer

22

14039614

NUT

23

231689

PIPE CONNECTOR

24

231812

RING NUT

25

231816

WASHER

26

248360

ELECTRIC PUMP BRACKET KIT

27

247213

HEAT GUARD

28

10979424

SCREW

30

226267

TIE-ROD

31

14054511

NUT

32

226266

BRACKET

33

11635724

SCREW

34

189936

CONNECTOR FASTENER BRACKET

35

227701

BRACKET

36

157386

CLIP

37

228135

BRACKET

38

139512

BRACKET WITH SHEATH

39

227557

CLAMP

40

217532

HEAT GUARD

40

207359

HEAT GUARD

41

217011

POWER UNIT MOUNTING BRACKET

42

248334

SCREW

43

10519424

WASHER

44

14059211

Nut

45

171746

SUPPORT CLAMP

49

16286127

SCREW

48

198960

CLAMP

50

14446624

WASHER

51

214620

SHIM

51

214621

SHIM
