No

Kod

Parça Adı

001

470831051G

Door (contact Your Area Manager-left)

001

470831052F

Door (contact Your Area Manager-right)

002

470837349C

Door Seal (left)

002

470837350C

Door Seal (right)

003

470831412F

Door Hinge (right)

003

470831411F

Door Hinge (left)

004

470837703E

Window Aperture Seal (left)

004

470837704C

Window Aperture Seal (right)

005

470837403F

Window Guide (from Vin Ela02674-left)

005

470837404F

Window Guide (from Vin Ela02674-right)

006

8L3837199B

Clip

007

470837917A

Door Seal (left)

007

470837918A

Door Seal (right)

008

8J0837805A

Sound Absorber (self-adhesive) (600x120/80x2,7)

009

470831437B

Cover (left)

009

470831438B

Cover (right)

010

8E0837033

REFERENCE

011

470837723B

Spring

012

470837646A

Ball Stud

013

470831548C

Cover (right)

013

470831547C

Cover (left)

014

N10049308

Screw M8X20

014

WHT008391

Hexagon Bolt (m8x20)

015

N90780903

SCREW M6X16.0

016

N10586401

SCREW ST 4,2X13

017

N10665002

SCREW

018

N10554005

SCREW M6X35

019

N01152527

WASHER

020

WHT005435

Countersunk Bolt (m8x30)

021

N91073301

Hexagon Socket Flat Head Bolt (m6x12-m6x12)

022

N90745001

NUT

023

N10017307

Hexagon collar nut (M5)

024

N91109201

WASHER

025

470831121B

Reinforcement For Door Handle (left)

025

470831122B

Reinforcement For Door Handle (right)

026

470831400A

Grommet

028

470837779

Intermediate Layer

029

N91030702

Hexagon Socket Flat Head Bolt (m4x8)
