No

Kod

Parça Adı

1

057 145 601 F

Electric compressor, D - 25.09.2017>>

2

36A 145 707 A

shield

3

36A 145 787 A

shield

4

057 145 897

connecting piece

5

36A 145 879 B

bracket for compressor, F 4V-J-019 375>>, F ZV-J-019 375>>

6

4M0 145 115

jounce bumper

7

N90215805

shouldered hex. nut, Discont./New add.+FULU calc.

8

N 911 287 01

socket hd. screw with, collar

9

06H 121 601 N

additional water pump

10

4G0 129 234

rubber isolator

11

WHT002306

screw, thread cutting

12

4M0 145 920 BE

water hose

13

1K0 121 093 CB

bracket for hose

14

N 107 915 01

bracket for hose

15

N 911 390 01

double hex. hd. bolt

16

N 909 203 02

rivetted cap nut

17

4M0 145 948 T

water hose with quick-, coupling piece

18

4M0 121 070 AC

water tube

20

867129669

grommet

21

1K0129734B

bushing, D - 12.03.2007>>

22

N 104 134 08

oval socket head bolt, with hex drive

25

4M0 145 568 B

water hose

26

N90686901

spring band clamp

27

WHT 007 714

spring clip

28

N90686701

spring clip, Only in combination with:, Only in combination with:

29

4M0 131 055 A

Vacuum line

30

1E0 955 787

clip

31

36A 145 709

pressure hose

35

N10518801

Hose Clamp

33

36A 145 943

pressure hose

34

N 107 355 01

Hose Clamp

36

4M0145950B

throttle valve

37

057 145 417 C

gasket, only to be used with:

38

06B905379G

temperature sensor, D - 18.09.2006>>

39

095 323 969

O-Ring

40

N90974701

Hexagon socket head panel bolt

41

N 104 056 04

Oval hexagon socket head bolt, only for:, D - 23.10.2017>>

41

N10451405

Oval hexagon socket head bolt, D - 20.03.2017>>

43

4M0 131 425

bracket

44

N91096701

Oval hexagon socket head bolt, D - 29.05.2006>>

45

1K0 906 283 A

solenoid valve

46

4M0 133 711

vacuum pipe

47

36A 133 710

vacuum hose
