No

Kod

Parça Adı

1

36A 407 151 A

control arm, only to be used with:, Note, technical product information:, F >> 4V-H-014 046, F >> ZV-H-014 046

1

36A 407 151 C

control arm, only to be used with:, D - 04.12.2017>>

1

36A 407 152 A

control arm, only to be used with:, Note, technical product information:, F >> 4V-H-014 046, F >> ZV-H-014 046

1

36A 407 152 C

control arm, only to be used with:, D - 04.12.2017>>

2

4M0 407 182

bonded rubber mounting, for use with:, Note, technical product information:, F >> 4V-H-014 046, F >> ZV-H-014 046

2

4M0 407 182 A

bonded rubber mounting, for use with:, F 4V-H-014 047>>, F ZV-H-014 047>>

3

4E0 407 181 B

bonded rubber mounting

4

WHT 007 028

12 point socket head screw

31

WHT 001 987

hex. nut, self-locking with, washer

19

WHT 006 151

shouldered hex. nut,, self-locking

7

4M0 407 693 E

wishbone link, D - 10.06.2016>>

7

4M0 407 694 E

wishbone link, D - 10.06.2016>>

8

4M0 407 183 B

hydro-mounting, D - 10.06.2016>>

9

N 108 176 01

Hexagon flange screw, (combi)

10

4M0 407 505 C

upper link

10

4M0 407 506 C

upper link

11

4M0 407 509 C

upper link

11

4M0 407 510 C

upper link

12

4M0 407 515 A

bonded rubber mounting

13

N 912 216 01

Hexagon flange screw, (combi)

15

WHT 006 542

Hexagon flange screw

16

N10272302

shouldered hex. nut,, self-locking

18

4M0 407 253 L

wheel bearing housing

18

4M0 407 254 L

wheel bearing housing

20

4M0 407 689 C

Swivel joint, control arm, only to be used with:, D - 26.08.2016>>

21

N 102 415 07

bolt, hex. hd. with shoulder

22

4M0 407 613

wheel hub, D - 27.03.2017>>

23

4M0498625G

wheel bearing with mounting, parts, D - 01.08.2016>>

24

WHT 006 966

Screw with int. serrations

25

8E0407643A

socket head bolt with inner multipoint head

26

4M0 413 037 H

Suspension fork, D - 02.05.2016>>

26

4M0 413 037 J

Suspension fork, D - 02.05.2016>>

26

4M0 413 038 H

Suspension fork, D - 02.05.2016>>

26

4M0 413 038 J

Suspension fork, D - 02.05.2016>>

28

N 102 722 02

bolt, hex. hd. (combi.)

29

N10106402

shouldered hex. nut,, self-locking, D >> - 12.06.2017

30

N 107 847 02

Hexagon flange screw
