No

Kod

Parça Adı

2

WHT 003 959

Hexagon head bolt

3

079 103 051 D

seal

4

N 911 679 01

threaded plug, D - 24.09.2015>>

5

057 103 138 F

insert

6

N 013 815 7

seal ring, D >> - 02.04.2016

7

057 103 153 AE

sealing flange

8

057 103 161 G

gasket

9

057 103 171 AQ

sealing flange

10

057 103 602 AM

oil sump-lower part

11

057103601AQ

Engine oil sump upper part

12

057 103 611 B

packing

14

057 103 609 D

gasket

15

059 103 158 R

jet

26

055 105 277

pin

17

059 103 051 K

seal

18

057105225G

shaft

19

022 103 139 B

sleeve

32

N 107 451 01

Hexagon socket flat, head bolt

21

N 011 903 4

sealing cap

24

N 011 904 7

sealing cap

23

N0119149

sealing cap, D - 29.05.2006>>

25

057 103 610 C

gasket

27

N 013 832 6

seal ring

29

N 911 965 01

threaded plug

55

N 101 961 03

fillister hd. screw with, MULTI-POINT SOCKET HEAD, to be used for:

33

N 107 453 01

Oval hexagon socket head bolt

35

D176501A1

silicone adhesive sealant, adhesives and sealing compound

37

WHT 004 873

fillister hd. screw with, MULTI-POINT SOCKET HEAD

38

WHT 004 874

fillister hd. screw with, MULTI-POINT SOCKET HEAD

39

N 910 547 01

Hex socket head locating bolt

40

079 907 660 A

oil level sensor, see illustration, item:

41

N 104 134 05

Hexagon socket flat, head bolt

42

059 103 323 D

thrust washer

45

057 105 223 A

sprocket

46

N 908 932 02

fitted bolt, hex. head

47

057 103 627 D

sealing cap

48

N 107 393 01

fillister hd. screw

51

059 103 869 D

needle bearing -

52

059 103 869 A

needle bearing -

53

057 103 139

sleeve

56

057 906 433 B

impulse sender

57

N 104 056 04

Oval hexagon socket head bolt, only for:, D - 23.10.2017>>

58

N 101 562 06

Oval hexagon socket head bolt

59

N10124306

Oval hexagon socket head bolt, D - 29.05.2006>>

60

057 109 130 K

cover, also use:

61

057 109 129 AK

cover, also use:

62

057 109 092 E

gasket, also use:

63

057 109 091 E

gasket, also use:

64

057 103 708 C

cover

65

057 103 147 L

gasket

66

N 910 215 02

round hd. screw
