No

Kod

Parça Adı

2

4M0 820 251 B

retainer plate

3

4M0 816 727 D

refrigerant line

4

4E0 260 749 C

seal ring

23

4E0260749B

seal ring

6

4M0 816 725 D

refrigerant line

7

4E0260749A

seal ring

14

4D0 260 749 B

seal ring

9

N10609201

shouldered hex. nut, D >> - 04.02.2013

10

4M0 820 181 B

expansion valve, for refrigerant:

10

4M0 816 181 A

expansion valve, for refrigerant:

11

N10723801

socket head bolt with inner, hex round head

12

4M0 816 885 F

refrigerant line

15

4H0 260 759 B

bracket for refrigerant pipe

29

N10582103

screw, csk. with polygon, socket hd., F 3W-6-036 941>>, F ZA-A-062 464>>

17

N90215805

shouldered hex. nut, Discont./New add.+FULU calc.

18

4H0 260 759 E

bracket for refrigerant pipe

19

4M0 820 769 E

bracket

20

N 904 953 01

hex. nut

21

8D0201441C

speed nut

22

4M0 816 886 A

refrigerant line

24

3D0260749C

seal ring

25

4M0 820 769 H

bracket

26

4F0 129 669 F

grommet

27

8Z0 129 734

bushing

28

N90887703

Hexagon flange nut,, self-locking

31

N 106 321 02

Oval hexagon socket head bolt
