No

Kod

Parça Adı

1

67635900

RH TGK VALVE

2

67444900

LH TGK Valve

3

254335

VALVE MOUNTING BRACKET

3

278753

VALVE FASTENER BRACKET

4

240729

CONNECTOR PIPE

15

262109

COLLAR

6

247947

RIGID TGK VALVE OUTLET PIPE

7

247949

CONNECTOR PIPE

8

155751

CLIP

8

252473

CLIP

9

12574017

NUT

10

12642878

Washer

11

67933600

TGK VALVE FASTENER ROD

12

64215300

CLIP

13

251945

PIPE FROM HEATER TO RH TGK VALVE

14

251946

PIPE FROM HEATER TO LH TGK VALVE

16

65460300

COMPLETE WATER PUMP

17

255370

BRACKET

18

14039614

NUT

19

11197774

Washer

20

231625

Screw

29

12643724

WASHER

22

103549

Cable Grommet

23

149707

SHIM

24

251944

DELIVERY PIPE FROM PUMP TO A/C

25

251947

PIPE FROM ENGINE TO PUMP

26

262111

Collar

27

256880

TGK PIPE SHIELD

27

283753

TGK PIPE SHIELD

28

10902224

SCREW

30

262271

CLAMP

31

10902424

Screw

32

10523401

WASHER

33

10444521

SCREW

34

81895900

GASKET

35

81970900

GASKET

36

160013

CLIP
