No

Kod

Parça Adı

1

83951500

RH CATALYTIC CONVERTER HEAT SHIELD

1

69760500

R.H. HEAT SHIELD

2

83951600

LH CATALYTIC CONVERTER HEAT SHIELD

2

69760600

L.H. HEAT SHIELD

12

80874100

Screw

17

67315400

WASHER

5

81175800

TUNNEL HEAT SHIELD

5

83951700

TUNNEL HEAT SHIELD

5

69761000

TUNNEL HEAT SHIELD

8

263737

TANK HEAT SHIELD

23

16296924

SCREW

11

83951800

RH HEAT SHIELD

11

82951500

SPARE WHEEL TUB HEAT SHIELD

14

86148300

RH LUGGAGE COMPARTMENT HEAT SHIELD

14

69761200

R.H. HEAT SHIELD TRUNK

15

86148400

LH LUGGAGE COMPARTMENT HEAT SHIELD

15

69761300

L.H. HEAT SHIELD TRUNK

16

82118300

SCREW -No longer supplied- -Replaced by 11625714-

18

287191

RH FRONT GEARBOX HEAT SHIELD

18

267806

FRONT RH GEARBOX HEAT SHIELD

19

287192

LH FRONT GEARBOX HEAT SHIELD

19

267807

FRONT LH GEARBOX HEAT SHIELD

20

231619

SCREW

26

16286024

Screw

21

254704

RH GEARBOX HEAT SHIELD

21

282637

RH GEARBOX HEAT SHIELD

21

261947

RH GEARBOX HEAT SHIELD

21

242697

RH GEARBOX HEAT SHIELD

22

254703

LH GEARBOX HEAT SHIELD

22

282922

LH GEARBOX HEAT SHIELD

22

261946

LH GEARBOX HEAT SHIELD

22

248741

LH GEARBOX HEAT SHIELD

24

246880

R.H. OIL PIPES HEAT SHIELD

25

246879

L.H. OIL PIPES HEAT SHIELD

26

16286124

SCREW

27

12643724

WASHER

28

83951900

LH HEAT SHIELD

28

83628300

LH HEAT SHIELD

28

82951800

RH HEAT SHIELD

29

13046112

NUT

30

82159500

CAP FOR SLOT

31

82299600

PLUG FOR FRONT MASTER POINT

32

82299500

PLUG FOR REAR MASTER POINT

33

263963

CABLE SHIELD

34

85833700

Screw

35

84290300

LOWER FASTENER BRACKET FOR LH HEAT SHIELD

35

84209700

LOWER FASTENER BRACKET FOR RH HEAT SHIELD

36

84451000

UPPER FASTENER BRACKET FOR LH HEAT SHIELD
