No

Kod

Parça Adı

1

3W5863315

carrier (leather cover)

2

3W0864447

guide pin

3

3W0864455

retaining pin

4

3W5863303

side panel trim (leather cover)

4

3W5863304

side panel trim (leather cover)

5

7M3858153

spring clip, D >> - 30.08.2011

6

3W5863338C

real wood inlay

7

3W5863337B

real wood inlay

8

3W5863535B

filler piece (leather cover)

9

3W0857618B

handle, bracket

10

3W5857717B

cover for stowage compartment centre console

11

3W5 858 337 K

stowage box

12

N91052001

round hd. screw

13

3W0857932

magnet, for sliding door

14

3W5863091H

stowage box

15

3W5863301A

cupholder tray

16

3W0858601B

cupholder console

22

3W5863289B

cover for ashtray, veneered

23

3W0858333B

cap, cover for ashtray

24

N 105 874 02

round hd. screw, D - 16.01.2017>>

20

3W5863267G

stowage box

21

3W1863911A

mounting plate

21

3W2863911B

mounting plate

21

3W5863911A

mounting plate

41

N90215805

shouldered hex. nut, Discont./New add.+FULU calc.

26

3W0863394

adjuster, (height adjustment), bracket

28

3W0864647D

distance plate

29

3W0864329E

bracket, armrest

30

3W0864339E

bracket, tunnel

31

3D0 813 929 B

bracket

32

N10017304

shouldered hex. nut, D >> - 03.01.2011

33

3W0864215

clip

34

3W0863203

clamping washer

35

N10434904

bolt, F 3Y-C-016 978>>, F ZH-C-016 978>>

36

N01508315

shouldered hex. nut, D >> - 10.02.2014

37

3W5857534

insert piece

38

3W5857532

insert piece

39

N01152220

Plastic washer

40

3W5863127A

chrome trim, switch

42

3W5863256

bracket

43

N10703001

round hd. screw

44

3W5863255

bracket

45

WHT003601

nut
