No

Kod

Parça Adı

2

3D0881105CQ

seat frame, with seat adjustment motors

2

3D0881105CT

seat frame, with seat adjustment motors

2

3D0881106DA

seat frame, with seat adjustment motors

2

3D0881106CR

seat frame, with seat adjustment motors

3

3D0 881 183 F

channel for seat with motor, for longitudinal adjustment, D - 12.05.2008>>

3

3D0 881 184 F

channel for seat with motor, for longitudinal adjustment, D - 12.05.2008>>

4

3W5881087D

cover, (manufactured to order,, refer to the colour table, on Bentley Hub)

5

3W5881088D

cover, (manufactured to order,, refer to the colour table, on Bentley Hub)

7

3W5 881 348

cap

8

3D0881449

retaining clip

9

3D0881250

limit stop sleeve for seat:

9

8E0881063A

limit stop sleeve for seat:

10

N90965002

socket head collared bolt with inner multipoint head

11

3D0 963 345 A

blower for seat, D - 23.04.2012>>

30

N10415903

Oval hexagon socket head bolt, D >> - 25.07.2011

13

3W5881405C

cover, cushion (leather)

13

3W5881405D

cover, cushion (leather)

13

3W5881405E

cover, cushion (leather)

13

3W5881406G

cover, cushion (leather)

13

3W5881406H

cover, cushion (leather)

13

3W5881406J

cover, cushion (leather)

14

3W5881553D

plastic foam, seat support

14

3W5881554F

plastic foam, seat support

15

3W5881373B

plastic foam, seat support

16

3W5858393B

bracket, seat

17

N10642801

hexagon socket head panel bolt

18

N90935902

oval hd. csk. self-tapp. screw

19

3D0881505A

reinforcement, trim panel for seat frame

19

3D0881506A

reinforcement, trim panel for seat frame

20

3D0881282

expanding nut

21

N10656501

tapping screw, fill. hd.

22

3W5881793

retainer for cover

22

3W5881794

retainer for cover

23

3W5881457

Cover section

23

3W5881458

Cover section

24

N90834301

speed nut

27

3W5 881 317 E

trim panel for seat frame

27

3W5 881 318 E

trim panel for seat frame

28

N90944603

Oval hexagon socket head bolt, only to be used with:

29

3W5881363

mounting
