No

Kod

Parça Adı

-

3W0 825 513

bracket, bracket for wheel housing

1

3W0 825 235 S

underbody lining, D - 17.08.2009>>

1

3W0825235T

underbody lining

2

4E0825241B

bracket, contains:, F 3W-4-020 001>> 3W-5-030 416

3

3W0825249

underbody lining

4

3W0825197B

sound absorber

4

3W0825198D

sound absorber

5

3W0825635C

sound absorber, tunnel, D - 28.11.2011>>

6

8D0805960

speed nut, D >> - 30.05.2005

7

3W0825199B

support bracket underbody trim

8

8D0805121

dowel pin

24

N90974701

Hexagon socket head panel bolt

10

3W0825228A

sound absorber

10

3W0825229A

sound absorber

12

N90327503

speed nut, D - 01.06.2005>>

13

N0901484

hexagon head bolt (combi)

14

4A0805137

rubber washer

15

N90983501

round hd. screw

16

N 903 350 06

clamping washer, D - 07.03.2016>>

17

N90320206

socket head bolt with hexagon socket head (combination) D - 29.05.2006>>

18

N10286110

shouldered hex. nut,, self-locking

19

3W5825495

underbody lining

20

N91052401

shouldered hex. nut plastic

21

8E0825265A

Attachment element

22

N91090701

oval socket head bolt, with hex drive, alternatively, you can use:

23

N90959101

speed nut, included in position:

25

N90215804

hex. nut, F >> 3W-G-051 745, F >> ZA-G-051 745
