No

Kod

Parça Adı

1

3W8831055C

door, D >> - MJ 2009, also use:

1

3W8831056C

door, D >> - MJ 2009, also use:

2

3D4 831 401 B

door hinge, D - 25.07.2011>>

2

3D4 831 402 B

door hinge, D - 25.07.2011>>

3

3D0831379C

spacer washer

3

3D0831379D

spacer washer

3

3D0831379E

spacer washer

3

3D0831380C

spacer washer

3

3D0831380D

spacer washer

3

3D0831380E

spacer washer

19

N90930503

multi-point socket head bolt with collar

5

3W0837249D

check strap - door

6

8Z0837257

pin

7

3W8837267

cover

7

3W8837268

cover

8

3W8867367P

gasket

8

3W8867368P

gasket

9

3W0837901C

window guide with, window slot seal

9

3W0837902C

window guide with, window slot seal

10

3W8837433M

gasket

10

3W8837434M

gasket

11

3W0837429B

check rod - door

11

3W0837430B

check rod - door

12

3W0837431G

gasket, guide

12

3W0837432G

gasket, guide

13

3W8867337D

gasket, door seal

14

3W7837475C

gasket

14

3W7837476C

gasket

15

3W8837513

gasket, door

15

3W8837514

gasket, door

16

3W0837703A

door seal, D - 03.01.2011>> - 03.10.2011

17

3W8847343C

gasket, D >> - 16.01.2012

18

N01470111

bolt, with hex. socket, hd., D >> - 14.02.2011

20

N0385053

spreader rivet

21

8Z0837111

bungs

22

4B0845643C

Hexagon socket oval head, panel bolt (combi), spring washer

23

3W8837155

gasket, insert

23

3W8837156

gasket, insert

24

N90823403

socket head bolt with inner multipoint head

25

3W8837615

bracket, gasket

25

3W8837616

bracket, gasket

26

N91153401

rivet

27

3W8864820

Adhesive tape
