No

Kod

Parça Adı

1

3W0121467B

air duct for charge, air cooler, D >> - MJ 2008

1

3W0121467D

air duct for charge, air cooler, D - 15.10.2007>>, also use:

2

3W0121221H

sealing element air guide for charge air cooler D - MJ 2009>>

3

3W0121468D

air duct for charge, air cooler, contains:, sealing tape, D >> - MJ 2008

3

3W0121468F

air duct for charge, air cooler, contains:, sealing tape, D - MJ 2009>>, also use:

4

3W0121281F

sealing element air guide for charge air cooler D - MJ 2009>>

5

3W8864820

Adhesive tape

6

3W0145803E

LH Intercooler / Charge Air Cooler

7

3W0145804E

RH Intercooler / Charge Air Cooler

8

867129669

grommet

9

1K0129734B

bushing, D - 12.03.2007>>

10

N10434904

bolt, F 3Y-C-016 978>>, F ZH-C-016 978>>

11

N90215805

shouldered hex. nut, Discont./New add.+FULU calc.

12

3W0806069B

Bracket for charge air cooler, D - 11.12.2006>>

12

3W0806070B

Bracket for charge air cooler, D - 11.12.2006>>

13

N10338302

set screw, D - 11.12.2006>>

14

038906051D

pressure sensor

15

N90172004

tapping screw, fill. hd.

16

3W0 145 828 H

pressure hose, charge air cooler, contains:, D - 03.03.2014>>

17

4W0 145 737 B

pressure hose, charge air cooler, contains:, D - 03.03.2014>>, D >> - MJ 2015

18

3W0 145 832 H

pressure hose, charge air cooler, contains:, D - 30.09.2013>>

19

4W0 145 738 A

pressure hose, charge air cooler, contains:, D - 03.03.2014>>, D >> - MJ 2015

20

N10731801

spring clip, D - 30.09.2013>> - 03.03.2014

21

N10518901

Hose Clamp

22

3W0145840F

charge air tube

23

N10248003

socket hd. screw with, collar, D - 11.12.2006>>

24

3W0145828E

pressure hose, charge air cooler

25

N10518801

Hose Clamp
