No

Kod

Parça Adı

1

3W7867015A

door trim panels

1

3W7867016A

door trim panels

2

3W7867101

housing (centre)

2

3W7867102

housing (centre)

3

3W0867677A

shaped part for anti-theft alarm system

4

3W8819695A

grille, side window

4

3W8819696A

grille, side window

5

3W0819079B

bracket for trim, side window

28

N10415903

Oval hexagon socket head bolt, D >> - 25.07.2011

7

3W0819869A

air guide channel

7

3W0819870A

air guide channel

8

3W0 868 463 E

grille, door panel, D - 20.04.2015>>

9

3W3867013D

insert piece

9

3W3867014D

insert piece

9

3W3867317G

insert piece

9

3W3867318G

insert piece

9

3W3867021B

insert, veneered

9

3W3867022B

insert, veneered

9

3W3867021DU63

insert piece (manufactured to order, refer to the colour table on bics)

9

3W3867022DU63

insert piece (manufactured to order, refer to the colour table on bics)

10

3W3868093A

bracket, door

11

3W3867191B

bracket, door

12

3W7867425

trim cover, Waistrail

12

3W7867426

trim cover, Waistrail

13

N91093601

clamping washer

14

3W7867347

housing (centre) end cap

14

3W7867348

housing (centre) end cap

15

3W0867899A

carrier mounting clip

16

6Q0868241

clip

17

3W3867131C

stowage box

17

3W3867132C

stowage box

18

3W3867413B

sound abs. for door trim panel

18

3W3867414B

sound abs. for door trim panel

19

3W0868667C

hinge, bag

20

3W3 867 085 C

trim for stowage dish, bag, D - 21.05.2007>>

20

3W3 867 086 C

trim for stowage dish, bag, D - 21.05.2007>>

21

3W8868193A

damper, door

22

3W0 868 467 C

Locating pin

23

N91083301

pop-rivet, only to be used with:

24

WHT000678

lock nut, alternatively, you can use:

25

N90994201

pop rivet

26

N90986802

hexagon socket head panel bolt

27

3W3867881

sound absorber, strip

29

3W0867721

pivot pin, hinge

30

3W0867299

clamp

31

3W0868424A

bracket

32

3W3837735

torch bracket

32

3W3837736

torch bracket

33

3W0867177

bracket, armrest

34

N90807402

hex socket oval head collared

35

N91091301

cup washer

36

N10655201

tapping screw, csk.

37

3W0868517

locking washer

38

3W0867847

damper, stop

39

3W3867749

retaining cable

40

N90562401

tapping screw, fill. hd.

41

N0115211

washer

42

3W3867339A

guide

43

N90833001

lock washer, FQA-TEIL
