No

Kod

Parça Adı

-

77010-74012

Tube Assy, Fuel Tank Vent

-

83320-74011

Gage Assy

-

77197-74010

Clamp, Evaporation Vent Tube

-

77035-74010

Cable Sub Assy, Fuel Lid Lock Control, LHD

-

77377-75010

Retainer, Fuel Filler Opening Lid Lock

-

77306-52050

Lever Sub Assy, Fuel Lid Lock Opening, RHD

-

77306-52040

Lever Sub Assy, Fuel Lid Lock Opening, LHD

-

77306-52060

Lever Sub Assy, Fuel Lid Lock Opening, LHD

1

77001-74010

Tank Assy

2

77196-12080

Clamp, Evaporation Vent Tube

3

77606-74011

Protector Sub-Assy, Fuel Tank, No 1

4

77602-74010

Band Sub-Assy, Fuel Tank, No 1 LH

7

77681-21020

Seat, Fuel Tank Band, LH

6

77601-74010

Band Sub-Assy, Fuel Tank, No 1 RH

8

90119-10951

Bolt. W/Washer

9

90179-06219

Nut, EL91

10

90467-09227

Clip

11

77652-74010

Cushion, Fuel Tank, No. 2

12

77651-74010

Cushion, Fuel Tank, No. 1

13

77010-74011

Tube Assy, Fuel Tank Vent

14

83320-74010

Gage Assy

15

77144-74010

Retainer, Fuel Pump Gauge

16

77169-74010

Gasket, Fuel Tank Suction Tube

17

77754-74010

Hose, Charcoal Canister Outlet, No.1, L=487

18

77026-74010

Tube Sub-Assy, Fuel Evaporation, No. 1

19

77027-74010

Tube Sub-Assy, Fuel Evaporation, No. 2

20

77028-74010

Tube Sub-Assy, Fuel Emission, Rear

21

96132-51100

Clamp, Fuel Hose

22

77197-42020

Clamp, Evaporation Vent Tube

23

82413-74010

Wire, Fuel Tank

24

77281-74010

Clamp, Fuel Hose

25

77024-74010

Plate Sub-Assy, Fuel Suction

26

23221-40010

Pump, Fuel

27

77652-74020

Cushion, Fuel Tank, No.2

28

77785-74010

Harness, Fuel Pump

29

23225-0T010

Spacer, Fuel Pump

30

23280-21010

Regulator Assy, Fuel Pressure

31

90301-04013

O Ring, No.1

32

77175-74010

Support, Fuel Suction, No.2

33

90301-08020

O Ring

34

90301-08019

O Ring, Fuel Pump

35

23217-40011

Filter, Fuel Pump

36

77209-74010

Tube Sub-Assy, Fuel Tank Main

37

77241-33011

Clip, Tube Joint

38

77017-74010

Tube Sub-Assy, Fuel Tank Vent

39

77210-74030

Pipe, Fuel Tank Filler

40

90119-10963

Bolt, W/Washer

41

77391-12020

Ring, Fuel Inlet Box

42

77291-52010

Shield, Fuel Tank Filler Pipe

43

77300-52030

Cap Assy, Fuel Tank

44

77350-74011

Lid Assy, Fuel Filler Opening

45

77366-52010

Spring, Fuel Filler Opening Lid Hinge

46

90269-06013

Rivet, Fuel Filler Opening Lid, MCV20

47

77035-74020

Cable Sub Assy, Fuel Lid Lock Control, RHD

48

77377-52020

Retainer, Fuel Filler Opening Lid Lock

49

77306-52030

Lever Sub Assy, Fuel Lid Lock Opening, RHD

50

64648-12020

Grommet, Luggage Door Lock Opening

51

90159-60602

Screw, with Washer

52

77333-74020

Clamp, Fuel Lid Lock Control Cable, No.2, RHD

53

77333-74010

Clamp, Fuel Lid Lock Control Cable, No.1

54

82711-2A250

Clamp, Fuel Lid Lock Control Cable

55

77333-74030

Retainer, Fuel Filler Opening Lid Lock
