No

Kod

Parça Adı

-

82730-74040

Block Assy, IP, AUTO

-

90982-08296

Fusible Link, 50A, Female, COLD CLIMATE SPEC, LHD

-

90982-08302

50A-30A-50A,FEMALE

-

90982-08306

Fusible Link, 30A, Terminal:Female, IP J/B

-

90982-08294

Fusible Link, 40A, Terminal: Female

-

90982-08295

Fusible Link, 30A, Terminal:Female, Engine Room R/B

-

90982-09020

Fuse, Fuse Block, 7.5A Mini Fuse

-

90982-09021

Fuse, Fuse Block, 10A Mini Fuse

-

90982-09022

Fuse, Fuse Block, 15A Mini Fuse

-

90982-09023

Fuse, Fuse Block, 20A Mini Fuse

-

90982-09024

Fuse, Fuse Block, 25A Mini Fuse

-

90982-09025

Fuse, Fuse Block, 30A Mini Fuse

-

89220-74120

Computer, Multiplex Network Body, RHD

-

89220-74030

Computer, Multiplex Network Body, LHD

-

89220-74040

Computer, Multiplex Network Body, COLD CLIMATE SPEC, LHD

-

82877-74010

Box, Computer Integration, RHS, LHD

-

89681-74020

Computer, Power management Control, Wirless Door Lock Smart Key, AUTO

14

90159-70003

Screw, W/Washer, RHD

1

82730-74060

Block Assy, IP, MAN

2

82673-74010

Bracket, Junction Block

3

90982-08300

Fusible Link, 50A-30A-50A, Female, COLD CLIMATE SPEC, LHD

4

90982-09019

Fuse, Fuse Block, 5A Mini Fuse

5

82672-74020

Cover, Junction Block

6

82673-74020

Bracket, Junction Block

7

94151-80600

Nut

8

89220-74060

Computer, Multiplex Network Body, UK SPEC, RHD

9

82878-74010

Box, Computer Integration, LHS, RHD

10

90159-60613

Screw, W/Washer

11

89681-74040

Computer, Power management Control, Wirless Door Lock Smart Key, MAN

12

85970-74010

Relay Assy, Double Lock Door Control, RHD

13

85940-74010

Relay Assy, Windshield Wiper

15

82660-74010

Block Assy, Relay

16

81980-46010

Flasher Assy, Turn Signal

17

82711-1E320

Clamp, Wiring

18

88280-42010

Switch Assy, Clutch

19

84520-42010

Switch Assy, Clutch Start

20

90170-10017

Nut

21

84340-19025

Switch Assy, Stop Lamp

22

84345-51010

Adjuster, Stop Lamp Switch Mounting

23

84550-16060

Switch Assy, Parking Brake

24

93315-14012

Screw, W/Washer

27

90987-02027

Relay, Daytime Running Light System, Cold Climate Spec, LHD

26

90987-02025

Relay, Heater, No.1
