No

Kod

Parça Adı

1

32-124654-AA

CONNECTOR COOLER PIPE RETURN

1

32-120301-AF

ASSY PIPE-COOLER RETURN-AUTO TRANS

2

32-124653-AA

CONNECTOR COOLER PIPE FEED

2

32-124670-AA

ADAPTER CONNECTOR PIPE (1/2 BSP)

2

32-120300-AG

PIPE ASSY COOLER FEED AUTO TRANS

3

42-86036

O RING

4

42120687AC

Clamping plate

5

703265

Screw, M6 x 16, Hex Flange Head

6

32-124652-AA

AUTO TRANSMISSION COOLER MIDDLE EAST

6

77-82546

SEAL-NUMBER PLATE HOUSING-790mm lg

6

699084

SCREW M6 x 18 FLG HD

6

33-81094

Strip, Edge Protection, 65mm

6

32-121643-AB

OIL COOLER AUTO TRAN BLACK

7

44-81589

MOUNTING RUBBER

8

44-81588

MTG BRKT-OIL COOLER

9

697121

NUT/WASHER ASSY-M6

10

32-121641-AC

PIPE ASSY COOLER FEED AUTO TRANS

11

32-121506-AA

CLAMP PLATE - TRANS COOLER PIPES

12

32-121500-AB

ASSY SUPPORT BRKT - TRANS COOLER PIPES

13

697106

SCREW M8 x 20 HEX FLANGE HD GRD 8.8

14

700332

Nut, M6, paint clearing

15

697123

WASHER 1/4 PLAIN FORM A

16

699328

`O RING 10.82ID x 1.78 VITON MANUAL G/BOX COOLING

19

37-122811-AA

CLIP

18

32-122836-AC

ASSY JUMP HOSE -AUTO TRANS COOLING

20

32-122324-AC

ASSY THERMOSTAT - AUTO TRANS COOLING

21

32-124726-AA

RETAINING PLATE OIL COOLER HOSE

21

37-81933

STRIP EDGE

21

700606

Screw, M6 x 12, Hex Flange Head
