No

Kod

Parça Adı

1

62-82396

BRACKET SUPPORT REAR WING RH

1

62-82397

BRACKET SUPPORT REAR WING LH

1

62-140064-AA

ASSEMBLY FRONT WING RH

1

62-140065-AA

ASSEMBLY FRONT WING LH

1

62-122662-AB

FRONT WING ASSY RH

1

62-122663-AB

FRONT WING ASSY LH

26

1R12-64-10183

SUPPORT ASSY- BONNET BUMPER

3

699125

SCREW M6 x 30 HEX 8.8

4

697516-PK

NUT-M6 HEX BLK (10)

5

FD43-E830667-AA-PK

Washer 25mm x 6.4mm-10

26

697811

WASHER M6 PLAIN LARGE OD S/LESS BLK

7

697728

SCREW-S/STEEL

8

697118

SCREW M5 x 16 HEX FLANGE HEAD GRD 8.8 ZINC PLATE

9

37-82038

WASHER 11/16in.od x 1/4in.id x 0.080in.t

10

697622

WASHER .20 PLAIN .20 X .75 OD X .04 T

13

702295

Nut, M5, Hex Flange Head

12

697636

M5 x 20 FLG HD

14

62-82400

SPACER-WING APRON

15

697488

SCREW No8 x 16 FLANGED AB S.T.

16

697487

NUT INSERT

17

78-82427

FINISHER GRILLE WING RH

17

78-82428

FINISHER GRILLE WING LH

17

78-125000-AB

FINISHER GRILLE WING RH

17

78-125001-AB

FINISHER GRILLE WING LH

17

78140070AB

Finisher, wing grille - RH

17

78140071AB

Finisher, wing grille - LH

17

78-140093-AA

ZAGATO Z BADGE

17

78140688AA

Push on fix, Z badge

17

696680

TAPE SELF ADHESIVE 35x50M

18

697295

NUT M4 HEX

19

697617

WASHER M4 PLAIN FORM C

20

697673

RAWLNUT M5

21

78-140068-AA

FRONT WING MESH GRILLE RH

21

78-140069-AA

FRONT WING MESH GRILLE LH

21

78-125386-AA

MESH GRILLE WING RH - GT

21

78-125387-AA

MESH GRILLE WING LH - GT

21

78-121468-AA

MESH GRILLE WING RH

21

78-121469-AA

MESH GRILLE WING LH

22

704690

ADHESIVE-TEROSTAT

23

37-81222

SIDE REPEATER FLASHER LAMP

24

37-123984-AA

HEADLAMP APERTURE FOAM

25

700606

Screw, M6 x 12, Hex Flange Head

26

78-140462-AA

FOAM STRIP - FRONT WING TO SILL RH

26

78-140463-AA

FOAM STRIP FRONT WING TO SILL

26

78-83155

BRACKET ASSY CLOSING LOWER RH

26

78-83156

BRACKET ASSY CLOSING LOWER LH

26

78-125113-AA

FRONT WING MOUNTING WASHER 20.5MM

26

78-125114-AA

FRONT WING MOUNTING WASHER 18.5MM

26

32-85306

Seal, Radiator Upper

26

78-123930-AA

SUPPORT RUBBER - FINISHER GRILLE-WING

26

78124938AA

Mounting washer, front fender

26

698988

SCREW M6x20-HEX HEAD BLACK
