No

Kod

Parça Adı

1

67-121449-BA

TRUNK LID ASSY COMP

1

67-121449-BB

TRUNK LID ASSY COMP

1

67-140101-AA

Trunk lid assy

1

67-150135-AA

Trunk lid assy, Federal

1

67-150143-AA

Trunk lid assy, Euro

1

67-121450-AA

TRUNK LID ASSY COMP COUPE

1

67-125254-AA

GT TRUNKLID ASSY COMPLETE

1

67-123100-AA

PROTECTION STRIP - TRUNK LID 110MM X 7M M

2

83124564AAW

Carpet assy, trunk lid, federal

2

83-124563-AAW

CARPET ASSY TRUNK LID - FEDERAL COUPE

2

83-111292-BAW

CARPET ASSY - TRUNK LID

2

83-111287-AAW

CARPET ASSY - TRUNK LID

57

85-82503-PK

FIRTREE FASTENER(20)

4

78-82435

FINISHER ASSY TRUNK LID

5

697472

SCREW M6 x 12 REC PAN HEAD 4.8

6

37-81223

NUMBER PLATE LAMP-RH

47

697485

WASHER M6 PLAIN FORM C

7

37-81224

NUMBER PLATE LAMP-LH

8

697798

SCREW-PAN HD S/TAP

10

69-83367

FOAM STRIP-1445 mm

10

78-123759-AA

FINISHER-TRUNK LID

11

37-83398

HOUSING ASSY- No.PLATE LIGHT LH

12

37-83397

HOUSING ASSY- No.PLATE LIGHT RH

13

697646

BOLT-M6 x 35 HEX HD GRADE 8.8

14

78-83401

SUPPORT PLATE ASSY- REAR No.PLATE-USA

14

78-83402

SUPPORT PLATE ASSY- REAR No.PLATE-JAPAN

15

700333

SCREW No10x19 S.T. FLANGED AB BLACK

16

697811

WASHER M6 PLAIN LARGE OD S/LESS BLK

17

80-123156-AA

LOCK TRUNK LID COMPLETE ASSY

18

37-123985-AA

H/LAMP APERTURE FOAM

18

67-123718-AA

CLIP-LOCK RETENTION

19

67-82587

TRUNK LATCH C/WITH MICROSWITCH

20

697115

SCREW M6 x 12 HEX HEAD GRD 8.8

36

697299

WASHER 1/4 S/PROOF INT

22

67150199AA

Tie rod, trunk lid lock

22

80-123147-AA

LINK - TRUNK LOCK

23

697290

PUSH ON FIXER-M3

24

37-82584

ACTUATOR-TRUNK LATCH

25

697542

SCREW NO8x25 PAN HD REC ST ZINC YEL PASS

26

67-82585

BRACKET TRUNK LATCH ACTUATOR MTG

27

697122

NUT M6 NYLOC

29

697543

SCREW 1/4 UNF x 3/8 HEX HD GRADE 8.8

30

697546

WASHER-LOCK

32

67-140248-AA

NUT ASSEMBLY BRACKET LOCK

32

700606

Screw, M6 x 12, Hex Flange Head

32

67-124959-AA

ROW ASSY BRACKET TRUNK LID LOCK

33

67-82588

STRIKER TRUNK LID LOCK

34

67-82590

RETAINER

35

697298

SCREW 1/4 UNF x 5/16 HEX HEAD

37

697286

Washer M6 Large OD

38

67-90160

FRICTION PLATE- BOOT LOCK STRIKER

39

6784675

Spacer, trunk hinge - 0.6mm

39

6784676

Spacer, trunk hinge - 1.0mm

39

67-83685

ASSY BOOTLID HINGE

39

67-84034

SHIM-T/LID HINGE

39

67-140227-AA

ASSEMBLY TRUNKLID HINGE COMPLETE

39

67150125AA

Hinge assy, trunk lid

39

67-80767

BOOT LID HINGE ASSY

40

FD43-E830667-AA-PK

Washer 25mm x 6.4mm-10

40

698988

SCREW M6x20-HEX HEAD BLACK

46

697540

SCREW M6 x 12 HEX HD GRADE 8.8 BLACK

42

67-84058

Gas Strut

43

1R12-640101-AA

Ball Stud

44

697548

NUT M8 NYLOC BLACK

45

67-82582

BRACKET ASSY - GAS STRUT MTG

48

77-90209

SEAL - BOOT LID (CONV)

48

77-140694-AA

SECONDARY TRUNKLID SEAL

48

77-86296

BOOT LID SEAL

48

77-124252-AA

SEAL TRUNK LID COUPE

48

77150114AA

Seal, trunk lid

49

67-83639

DRAIN TUBE-TRUNK (DB7CONV) RUBBER

50

692634

HOSE-CLIP

51

67-83640

GROMMET (DB7CONV)

52

65-82268

PAD DOOR LOCK

53

67150140AB

Mechanism assy, federal trunk latch

53

67-124570-AA

ASSY FEDERAL TRUNK LATCH MECHANISM

53

67-124574-AA

FEDERAL LATCH MECHANISM CABLE

53

1R12-67-10146

EMERGENCY PULL TAG

53

697470

NUT M5 NYLOC

53

697636

M5 x 20 FLG HD

53

AD43-19G329-AA

WARNING TRIANGLE ASSY

53

699887

Pop rivet, 4.8 x 19 large head, black

53

699888

NYLON WASHER 6.5 X 15 X 5 THK

54

1R12-67-10184

BRACKET-W/TRIANGLE

55

67-124081-AA

RETAINER PLATE

56

67-124028-AA

CAPTIVE BOOT LATCH STRIKER

56

703188

SCREW M8 x1.25 x 20 FLANGE HEX HEAD CHROME FREE

56

86-82450

SPACER

56

67-150144-AA

STRIKER - TRUNKLID LOCK

57

67-140555-AA

EMERGENCY BOOT RELEASE CABLE

57

83140384AAW

Trim panel assy, trunk lid, RH

57

83140385AAW

Trim panel assy, trunk lid, LH

57

77140696AA

Water shedder, trunk lid, RH

57

77140697AA

Water shedder, trunk lid, LH

57

67-140597-AA

BRACKET BOOT RELEASE CABLE

57

693476

GROMMET 19x25.5P/HL

57

67140661AA

Gasket, upper nutplate, strap, bootlid retaining

57

67140657AA

Gasket, bracket, strap, bootlid retaining

57

67-140658-AA

UPPER NUTPLATE STRAP RESTRAINING BOOTLID

57

67-140668-AA

UPPER BRACKET STRAP RESTRAINING BOOTLID

57

67-140655-AA

NUTPLATE STRAP RESTRAINING BOOTLID

57

67140654AA

Bracket, strap, bootlid retaining

57

67-140653-AA

STRAP RESTRAINING BOOTLID

57

67140656AA

Clevis pin, strap, bootlid retaining

57

67140659AA

Circlip, external, st stl

57

65-83577

BUMP STOP RUBBER

57

67140669AA

Screw, M5 csk skt hd

57

697666

Adhesive tape, double sided

57

83150202AAW

Trim panel assy, centre boot lid, complete

57

83150199AAW

Trim panel assy, lower bootlid, complete

57

83150200AAW

Trim panel assy, trunk lid, RH

57

83150201AAW

Trim panel assy, trunk lid, LH

57

83-124600-AA

EMERGENCY TRUNK HANDLE BRACKET

57

582-000-2829

POP-RIVET 3.2mm CSK

57

697528-PK

Washer-M5 Large OD Pack of 20

57

83-84823

SNAPSAC
